Product Name: SM 1222 Digital Output Module
Brand Name: Siemens
Model Number: 6ES7222-1HH32-0XB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Overview
The Siemens 6ES7222-1HH32-0XB0 is an SM 1222 digital output module developed for the SIMATIC S7-1200 automation platform. It is designed to expand the digital output capacity of PLC systems by providing reliable relay-based signal switching for industrial applications.
The module features 16 digital relay outputs capable of controlling both AC and DC loads. Its flexible voltage compatibility and robust relay switching capability make it suitable for operating actuators, lamps, contactors, solenoid valves, and other industrial field devices requiring stable electrical control.
With its compact modular design and seamless integration into S7-1200 systems, the 6ES7222-1HH32-0XB0 offers an efficient solution for machine automation, production line control, and industrial process applications where dependable output switching performance is essential.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7222-1HH32-0XB0 SM 1222 Digital Output Module |
| Manufacturer | Siemens |
| Product Type | SM 1222 Digital Output Module |
| Part Number | 6ES7222-1HH32-0XB0 |
| Estimated shipping dimensions | 4.4x7.4x9.9cm |
| Weight | 0.22kg |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Product type designation | SM 1222, DQ 16x relay/2 A |
| permissible range, lower limit (DC) | 20.4 V |
| permissible range, upper limit (DC) | 28.8 V |
| from backplane bus 5 V DC, max. | 135 mA |
| from load voltage L+, max. | 11 mA/relay coil |
| Power loss, typ. | 8.5 W |
| Number of digital outputs | 16 |
| in groups of | 1 |
| Short-circuit protection | No; to be provided externally |
| with resistive load, max. | 2 A |
| On lamp load, max. | 30 W with DC, 200 W with AC |
| Rated value (DC) | 5 V DC to 30 V DC |
| Rated value (AC) | 5 V AC to 250 V AC |
The Siemens 6ES7222-1HH32-0XB0 digital output module is designed for use in industrial automation environments and is typically installed inside protected electrical control cabinets. The module is mounted on standard DIN rails as part of the SIMATIC S7-1200 system architecture.
The module operates with a stable 24V DC industrial power supply and is intended for continuous operation in factory automation systems. Its relay-based outputs are suitable for switching a variety of AC and DC industrial loads, including lamps, contactors, solenoid valves, and other control devices commonly used in production environments.
Engineered for industrial reliability, the module can withstand environments with electrical interference, vibration, and long operating cycles. Its compact and modular structure allows efficient installation in space-constrained control panels while maintaining stable and dependable switching performance.
