Siemens 6ES7223-1BL32-0XB0 Digital I/O Module

Siemens 6ES7223-1BL32-0XB0 Digital I/O Module

Product Name: Digital I/O Module

Brand Name: Siemens

Model Number: 6ES7223-1BL32-0XB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

Overview
Functions
Features
Contact Info
Commercial Terms
Parameter
Application Scenarios
Operating Environment
Recommended Products

Overview

The Siemens 6ES7223-1BL32-0XB0 is a compact and high-density digital I/O expansion module designed for the Siemens SIMATIC S7-1200 PLC series. It integrates 16 digital inputs and 16 digital transistor outputs in a single module, enabling efficient control and monitoring for medium-sized industrial automation systems. Operating on 24 V DC, the module delivers reliable signal processing, low power consumption, and stable performance in demanding industrial environments.

Compared with lower-density modules such as SM 1231 and SM 1232, the SM 1223 significantly increases I/O capacity without enlarging the PLC installation footprint, making it ideal for compact automation architectures.

Functions

Provides 16 digital inputs for receiving field signals from sensors, switches, and control devices.
Provides 16 digital transistor outputs for controlling actuators, relays, solenoids, indicators, and other field equipment.
Supports reliable 24 V DC signal detection with high noise immunity.
Enables both sinking and sourcing output applications for flexible industrial integration.
Expands the I/O capability of Siemens S7-1200 PLC systems without requiring additional controller hardware.
Ensures electrical isolation between channels and the backplane bus for enhanced system protection and operational safety.

Features

High-density 16 DI / 16 DO configuration for space-saving PLC expansion.
Stable 24 V DC operation with a permissible voltage range of 20.4 V to 28.8 V.
Low power consumption with typical power loss of only 4.5 W.
Fast and accurate digital signal recognition:
- Logic “0”: 5 V DC at 1 mA
- Logic “1”: 15 V DC at 2.5 mA
Transistor outputs capable of handling up to 0.5 A per channel.
Maximum backplane current consumption of 185 mA.
500 V AC electrical isolation between channels and backplane bus.
Compact and lightweight design:
- Dimensions: approximately 7 × 7.5 × 10 cm
- Weight: 0.26 kg
Designed for high reliability in harsh industrial conditions.
Manufactured in Germany with Siemens industrial quality standards.

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Parameter

Product Name	Siemens 6ES7223-1BL32-0XB0 Digital I/O Module
Manufacturer	Siemens
Product Type	Digital I/O Module
Part Number	6ES7223-1BL32-0XB0
Estimated shipping dimensions	7x7.5x10cm
Weight	0.26kg
Place of shipment	Xiamen, China
Country of origin	Germany
Product type designation	SM 1223, DI 16x24 V DC, DQ 16x24 V DC
Rated value (DC)	24 V
permissible range, lower limit (DC)	20.4 V
permissible range, upper limit (DC)	28.8 V
from backplane bus 5 V DC, max.	185 mA
from load voltage L+ (without load), max.	4 mA; per channel
Power loss, typ.	4.5 W
Number of digital inputs / outputs	16
Rated value (DC)	24 V
for signal	5 V DC at 1 mA
for signal	15 V DC at 2.5 mA
up to 50 째C, max.	8 A; Current per mass between the channels and backplane bus 500 V AC
Ambient temperature during operation	-20 °C - 60 °C
Ambient temperature during storage/transportation	-40 °C - 70 °C
Air pressure	660 hPa - 1 080 hPa
Relative humidity	95%

Application Scenarios

The Siemens 6ES7223-1BL32-0XB0 is suitable for a wide range of industrial automation applications, including:

Factory automation systems
Conveyor and material handling systems
Packaging machinery
Assembly production lines
Process control systems
Water and wastewater treatment plants
Building automation systems
Energy management systems
Machine control panels
Industrial monitoring and signal interfacing applications

Its high channel density makes it especially suitable for compact control cabinets where space optimization is important.

Operating Environment

The Siemens 6ES7223-1BL32-0XB0 is designed for reliable operation in demanding industrial environments. It supports an operating temperature range from -20 °C to 60 °C and can withstand storage and transportation temperatures from -40 °C to 70 °C. The module operates effectively under air pressure conditions ranging from 660 hPa to 1 080 hPa and can tolerate relative humidity levels up to 95%. With robust insulation rated at 500 V AC between channels and the backplane bus, the module ensures stable and secure performance even in environments with electrical noise, temperature fluctuations, and high humidity.
