4 AI
Analog inputs |
Voltage / current
Selectable ranges |
12 bit
Maximum resolution |
Siemens SIMATIC S7-200 SMART 6ES7288-3AE04-0AA0 is the SM AI04 module described by Siemens as Analog input SM AI04, 4 analog inputs, 0...10 V, 0...5 V, +/-5 V, +/-2.5 V or 0/4...20 mA; 11 bit + sign (12 bit ADC).
Product type designation: SM AI04, AI 4x12 bit. Confirm the complete article number and current documentation revision before quotation.
Article number |
6ES7288-3AE04-0AA0 |
Series |
SIMATIC S7-200 SMART |
Official description |
Analog input SM AI04, 4 analog inputs, 0...10 V, 0...5 V, +/-5 V, +/-2.5 V or 0/4...20 mA; 11 bit + sign (12 bit ADC) |
Core verified point |
4 AI analog inputs |
|
Article number
|
6ES7288-3AE04-0AA0
|
|
Analog inputs
|
4
|
|
Input ranges
|
0...10 V, 0...5 V, +/-5 V, +/-2.5 V or 0/4...20 mA
|
|
Product type designation
|
SM AI04, AI 4x12 bit
|
|
Maximum resolution
|
12 bit; voltage mode 11 bit + sign, current mode 11 bit
|
|
Rated supply
|
24 V DC; permissible range 20.4 to 28.8 V DC
|
|
Current consumption, typical
|
40 mA
|
|
Backplane bus current at 5 V DC, typical
|
80 mA
|
|
Power loss, typical
|
1.5 W
|
|
Thermocouple / RTD / resistance input
|
Not supported according to the official datasheet
|
|
Module profile
SM AI04, AI 4x12 bit |
Wiring status
Exact pin allocation must be confirmed from the official manual. |
Configure every channel for its actual signal type and range. Confirm the terminal assignment, reference potential, shielding and conductor routing in the current Siemens system manual before wiring.
Do not copy a terminal assignment from a similar module. Confirm signal references and supply terminals for 6ES7288-3AE04-0AA0 before installation.
|
Signal protection
|
Confirm transmitter, actuator, surge and circuit-protection coordination for the actual installation.
|
|
Cabinet environment
|
Ambient temperature, humidity, altitude, pollution degree and enclosure selection are subject to verification.
|
|
Cable practice
|
Confirm shielding, grounding, separation and reference-potential instructions in the official manual.
|
|
Approvals
|
Required certificates and their current revisions are available on request and subject to verification.
|
|
Module identity
|
Protection and environmental decisions must use the exact article number 6ES7288-3AE04-0AA0.
|
|
01
|
Confirm the complete article number: 6ES7288-3AE04-0AA0.
|
|
02
|
Confirm sensor output type, selected voltage/current range, channel count, resolution requirement and CPU/system compatibility.
|
|
03
|
Confirm signal references, shielding, grounding and terminal assignment.
|
|
04
|
Confirm available expansion capacity and CPU/system compatibility.
|
|
05
|
Confirm environmental limits and any required approvals.
|
|
06
|
Record the selected ranges and wiring decisions in the quotation request.
|
|
Identity
|
Match 6ES7288-3AE04-0AA0 and the complete suffix on the product nameplate.
|
|
Signal profile
|
Verify every configured analog range against the connected field device.
|
|
Condition
|
Confirm New, Used or Refurbished before quotation.
|
|
Photos
|
Current physical-product and nameplate photos are available on request.
|
|
System fit
|
Verify CPU, module position and available expansion capacity.
|
|
Electrical fit
|
Verify supply, signal references, load and grounding.
|
|
Documents
|
Confirm the latest Siemens datasheet and system manual.
|
|
Commercial record
|
Check the written quotation, payee information and agreed transaction terms.
|
|
Stock status
|
Subject to verification. Request current inventory evidence for 6ES7288-3AE04-0AA0.
|
|
Condition
|
New, Used or Refurbished: confirm before quotation.
|
|
Current photos
|
Physical-product and nameplate photos are available on request.
|
|
Warranty
|
Confirm before quotation.
|
|
Dispatch time
|
Confirm before quotation.
|
|
Testing
|
Subject to verification; available test records can be requested.
|
|
Payment methods
|
Available on request and subject to the written quotation.
|
|
Quotation response time
|
Subject to verification.
|
|
Transaction confidence
|
Request company details, written quotation, payee verification and an agreed transaction record before payment.
|
|
