Product Name:3300 XL 8 mm Proximity Probes
Brand Name:BENTLY NEVADA
Model Number:330103-07-12-10-02-00
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Bently Nevada |
Model Number: |
330103-07-12-10-02-00 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Item |
Specification |
|
Product Model |
330103-07-12-10-02-00 |
|
Series |
3300 XL 8 mm Proximity Probe |
|
Thread Type |
M10 x 1 Metric Thread |
|
Probe Type |
Eddy current non-contact sensor |
|
Cable Type |
Coaxial / FluidLoc optional |
|
Length Options |
0.5 m to 9.0 m system range |
|
Connector Type |
ClickLoc gold-plated connector |
|
Temperature Range |
-52°C to +177°C (standard) |
|
Dimension (Probe) |
2x1.5x122cm |
|
Weight |
0.1kg |
The 3300 XL 8 mm Proximity Transducer Probe System – Model 330103-07-12-10-02-00 is a high-performance eddy current sensing solution designed for precise vibration and shaft position monitoring in rotating machinery. It is part of the advanced Bently Nevada 3300 XL series, engineered for industrial reliability and long-term stability in harsh operating environments.
This system works together with a matching extension cable and Proximitor sensor to deliver a stable voltage output proportional to the distance between the probe tip and target surface. It supports both static and dynamic measurement applications, including vibration analysis, speed detection, and Keyphasor reference signals.
Built for API 670-compliant performance, the 3300 XL 8 mm series ensures full interchangeability between components without recalibration. The model 330103-07-12-10-02-00 offers robust mechanical construction, improved EMI/RFI resistance, and reliable operation in power generation, petrochemical, and industrial automation systems.
Q1: What is the 330103-07-12-10-02-00 used for?
A1: It is used for vibration, displacement, and shaft position measurement in rotating industrial machinery.
Q2: Is the 3300 XL 8 mm probe compatible with other Bently Nevada systems?
A2: Yes, it is fully interchangeable with other 3300 XL proximity system components.
Q3: Can this probe operate in high-temperature environments?
A3: Yes, it supports operation up to +177°C under standard conditions.
Q4: What industries commonly use this probe?
A4: It is widely used in power plants, petrochemical plants, steel mills, and manufacturing systems.
Q5: Does the system require calibration when replacing parts?
A5: No, components are factory-calibrated and designed for plug-and-play interchangeability.
| Number | Describe |
|---|---|
| 141078 | 3300 XL 8 mm and 3300 5 mm Proximity Transducer System Manual. |
| 175751 | 3300 XL Multi-Purpose Stainless Steel Housing (12”×12”×6”), supports up to 8 Proximitor Sensors in DIN-mount or 6 in panel-mount configuration, available with ATEX Zone 0 and Zone 1 certifications. |
| 176467 | 3300 XL Multi-Purpose Stainless Steel Housing (12”×8”×6”), supports up to 4 Proximitor Sensors in DIN-mount and panel-mount configurations, available with ATEX Zone 0 and Zone 1 certifications. |
| 330181 | 3300 XL Multi-Purpose Stainless Steel Housing (13”×9.5”×7”), supports up to 8 Proximitor sensors in DIN-mount or 6 in panel-mount configuration, with hazardous area approvals including ATEX Zone 0/1 and North American Division 1/2. |
| 02120015 | Bulk field wire: 1.0 mm² (18 AWG), 3-conductor, twisted shielded cable with drain wire. Length specified in feet. |
| 138492-01 | Replacement panel-mount mounting pad for 3300 XL system installations. |
| 138493-01 | Replacement DIN-mount mounting pad for 3300 XL system installations. |
| 148722-01 | 3300 XL test plug with 3 color-coded wires and banana plugs for Proximitor sensor testing without removing field wiring. |
| 04310310 | 3300 XL Proximitor Sensor panel-mount screw (6-32 UNC). Four screws required per sensor, supplied with housings. |
| 03200006 | Silicone self-fusing tape (9.1 m roll) for connector protection and environmental sealing. Not recommended for internal machine use. |
| 40113-02 | Connector Protector Kit for 3300 XL 8 mm probes and extension cables, includes protectors and installation tools. |
| 136536-01 | Connector protector adapter for compatibility with pre-1998 installation tools and 75Ω ClickLoc connectors. |
| 40180-02 | Connector protectors package (10 pairs) for 3300 XL 8 mm probes and extension cables, providing environmental sealing. |
| 03839410 | 75Ω triaxial male connector protector for extension cable side, used for environmental protection of connectors. |
| 03839420 | 75Ω triaxial female connector protector for probe lead or Proximitor sensor connection protection. |
| 04301007 | 3/8-24 probe lock nut with safety wire holes for secure mechanical locking in probe installations. |
| 04301008 | M10 x 1 probe lock nut with safety wire holes for secure probe mounting in industrial applications. |
