Siemens SIMATIC S7-200 SMART 6ES7288-3AM03-0AA0 Analog I/O SM AM03 2 AI 1 AO 12-bit / 11-bit

Siemens SIMATIC S7-200 SMART 6ES7288-3AM03-0AA0 Analog I/O SM AM03 2 AI 1 AO 12-bit / 11-bit

6ES7288-3AM03-0AA0
SIMATIC S7-200 SMART SM AM03

2 AI + 1 AO
Analog I/O

12 bit / 11 bit
AI / AQ resolution

45 x 100 x 81 mm
Module dimensions

Selection gate: Confirm the two input signal types, the single output signal type, required resolutions, load, common/reference wiring and system compatibility.

Email Inquiry WhatsApp[email protected] | +86 18159889985

Overview
Applications
Data
Construction
Environment
Selection
Verification
Commercial
Models
Recommended Products

Product Overview

Official identification and verified analog profile

Siemens SIMATIC S7-200 SMART 6ES7288-3AM03-0AA0 is the SM AM03 module described by Siemens as Analog I/O SM AM03, 2 analog inputs and 1 analog output; supported input voltage/current ranges with 12-bit maximum input resolution and 11-bit analog output resolution.

Product type designation: SM AM03, AI 2x12 bit, AQ 1x11 bit. Confirm the complete article number and current documentation revision before quotation.

Article number	6ES7288-3AM03-0AA0
Series	SIMATIC S7-200 SMART
Official description	Analog I/O SM AM03, 2 analog inputs and 1 analog output; supported input voltage/current ranges with 12-bit maximum input resolution and 11-bit analog output resolution
Core verified point	2 AI + 1 AO analog i/o

Applications

Analog expansion purpose

Compact mixed analog expansion for a station needing two supported analog measurements and one supported analog command signal.
Use only supported signal ranges stated for this exact order number.
Confirm field-device electrical characteristics, reference wiring and shielding before installation.
Application suitability remains subject to verification against the current Siemens manual.

Application gate: Confirm the two input signal types, the single output signal type, required resolutions, load, common/reference wiring and system compatibility.

Data

Article number	6ES7288-3AM03-0AA0
Analog inputs	2
Analog outputs	1
Input ranges	0...10 V, 0...5 V, 0/4...20 mA, +/-5 V and +/-2.5 V
Output ranges	+/-10 V or 4...20 mA
Product type designation	SM AM03, AI 2x12 bit, AQ 1x11 bit
Power consumption	1.1 W, no load
SM bus current consumption	60 mA
24 V DC current consumption	30 mA no load; 50 mA with 20 mA load per channel
Dimensions W x H x D	45 x 100 x 81 mm
Weight	172 g

Source control: Data above is limited to the official Siemens product record and system manual. Confirm the applicable revision before quotation.

Construction

Signal and terminal construction

Module profile
SM AM03, AI 2x12 bit, AQ 1x11 bit

Wiring status
Exact pin allocation must be confirmed from the official manual.

The mixed I/O arrangement requires separate confirmation of input-channel ranges, output range, reference terminals and functional-earth connection. Use the exact AM03 connector table in the official manual.

Do not copy a terminal assignment from a similar module. Confirm signal references and supply terminals for 6ES7288-3AM03-0AA0 before installation.
