Siemens 6ES7314-1AF10-0AB0 SIMATIC S7-300 CPU 314 Original new

Siemens 6ES7314-1AF10-0AB0 SIMATIC S7-300 CPU 314 Original new

Product Name:SIMATIC S7-300 CPU 314

Brand Name:Siemens

Model Number:6ES7314-1AF10-0AB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7314 1af10 0ab0 simatic s7 300 cpu 314 original new-1

Overview
Inquiry now
Specifications
Description
Applications
Control & Communication
Construction, Interfaces, and Safety Features
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7314-1AF10-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Inquiry now

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7314-1AF10-0AB0
Product Name	SIMATIC S7-300 CPU 314
Manufacturer	Siemens
Product Type	Central Processing Unit (CPU)
Series	SIMATIC S7-300
Communication Interface	Integrated MPI (RS485)
Supply Voltage	24 V DC (20.4–28.8 V DC)
Working Memory	48 KB Integrated
Load Memory	Micro Memory Card (MMC), up to 8 MB
Programming Software	STEP 7 V5.1 SP4 or later
Digital I/O Capacity	1,024 Inputs / 1,024 Outputs
Analog I/O Capacity	256 Inputs / 256 Outputs
MPI Transmission Rate	Up to 187.5 kbit/s
Typical Power Consumption	2.5 W
Maximum Racks	4
Dimensions	40 × 125 × 130 mm
Weight	Approx. 280 g

Description

The 6ES7314-1AF10-0AB0 is a Siemens SIMATIC S7-300 CPU 314 engineered for reliable control in medium-sized industrial automation systems. Featuring an integrated MPI interface, built-in 24 V DC power supply, and 48 KB of working memory, it delivers fast data processing and dependable performance for machine control, process automation, and distributed production applications. A Micro Memory Card (MMC) is required for program storage and long-term data retention.

As a member of the SIMATIC S7-300 family, the 6ES7314-1AF10-0AB0 supports STEP 7 engineering software and offers high-speed instruction execution, flexible communication, and efficient memory management. It is compatible with a wide range of Siemens communication processors and function modules, allowing scalable system expansion.

Designed for long-term industrial operation, the 6ES7314-1AF10-0AB0 helps improve production efficiency, minimize downtime, and simplify maintenance. It is widely deployed in manufacturing, water treatment, energy, material handling, packaging, and OEM automation projects where stable PLC performance and reliable communication are essential.

Applications

Power plants: Performs turbine auxiliary control, generator monitoring, process sequencing, and equipment status acquisition.
Substations: Supports electrical signal collection, relay coordination, automation control, and communication with supervisory systems.
Chemical plants: Executes continuous process automation, instrument monitoring, batching control, and production management.
Steel mills: Controls rolling mills, conveyors, hydraulic systems, and production equipment operating in demanding industrial environments.
Machinery manufacturing plants: Provides PLC control for robotic workstations, assembly lines, CNC equipment, and automated packaging machinery.
Water treatment facilities: Manages pumping stations, filtration systems, dosing equipment, and distributed process control.
Food and beverage industry: Automates filling, conveying, packaging, labeling, and production monitoring for efficient manufacturing.

Control & Communication

Integrated MPI interface enables reliable PLC programming and diagnostics.
Supports Siemens S7 communication and Global Data communication services.
Compatible with STEP 7 engineering software for efficient project development.
Supports PG/OP communication for commissioning and maintenance.
Provides up to 12 communication connections for engineering and operator stations.
Expandable through Siemens communication processors (CPs).
Supports real-time data exchange with distributed automation equipment.
Stable RS485 communication improves industrial network reliability.

Construction, Interfaces, and Safety Features

Compact S7-300 module design simplifies cabinet installation.
Built-in 24 V DC power supply reduces additional wiring requirements.
Integrated hardware clock with battery backup maintains accurate timekeeping.
Maintenance-free program storage using Siemens Micro Memory Card technology.
Password protection safeguards user programs against unauthorized access.
Diagnostic buffer supports rapid fault detection and maintenance.
Rugged industrial construction ensures dependable long-term operation.
Designed for continuous automation applications requiring stable and secure PLC performance.

FAQ

Q1: What is the 6ES7314-1AF10-0AB0 used for?
A1: It is a Siemens SIMATIC S7-300 CPU designed for medium-sized industrial automation, machine control, and process applications.

Q2: Does the 6ES7314-1AF10-0AB0 require a Micro Memory Card?
A2: Yes. A Siemens MMC is required for program storage, startup, and maintenance-free data backup.

Q3: Which communication interface is integrated into the 6ES7314-1AF10-0AB0?
A3: The CPU includes an integrated MPI interface based on RS485 communication technology.

Q4: Which software is used to program the 6ES7314-1AF10-0AB0?
A4: It supports Siemens STEP 7 V5.1 SP4 and later versions for programming and configuration.

Q5: Which industries commonly use the 6ES7314-1AF10-0AB0?
A5: It is widely applied in power generation, manufacturing, chemical processing, water treatment, logistics, packaging, and OEM industrial automation systems.
