Product Name: CPU 314C-2 PTP Compact CPU
Brand Name: Siemens
Model Number: 6ES7314-6BH04-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7314-6BH04-0AB0 CPU 314C-2 PTP Compact CPU |
| Manufacturer | Siemens |
| Product Type | CPU 314C-2 PTP Compact CPU |
| Part Number | 6ES7314-6BH04-0AB0 |
| Weight | 0.65kg |
| Estimated shipping dimensions | 12x12.2x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| HW functional status | 1 |
| Firmware version | V3.3 |
| Rated value (DC) | 24 V |
| permissible range, lower limit (DC) | 19.2 V |
| permissible range, upper limit (DC) | 28.8 V |
| Mains/voltage failure stored energy time | 5 ms |
| Current consumption (rated value) | 660 mA |
| Current consumption (in no-load operation), typ. | 150 mA |
| Inrush current, typ. | 5 A |
| Power loss, typ. | 13 W |
The Siemens 6ES7314-6BH04-0AB0 CPU 314C-2 PTP Compact CPU is a powerful programmable logic controller (PLC) designed for compact and medium-scale industrial automation applications. As part of the SIMATIC S7-300 family, it combines CPU processing capabilities with integrated I/O functionality, providing a space-saving and cost-effective solution for machine control, manufacturing systems, and process automation.
Featuring integrated point-to-point (PTP) communication capabilities, the CPU enables efficient serial communication with external devices such as barcode readers, weighing systems, printers, and operator interfaces. Its compact architecture simplifies system design while maintaining the performance required for demanding industrial control tasks.
Automation Program Execution
Executes user-defined control logic, sequencing, and automation tasks in real time.
Integrated I/O Processing
Processes field signals directly through built-in I/O resources, reducing the need for additional modules.
Point-to-Point Communication
Supports serial communication with external devices such as printers, scanners, and instrumentation systems.
Machine and Process Control
Coordinates industrial equipment, machinery, and process operations with deterministic control performance.
Data Handling and Processing
Manages operational data, control parameters, and system diagnostics efficiently.
System Monitoring & Diagnostics
Provides status monitoring and diagnostic functions to improve troubleshooting and maintenance efficiency.
Industrial Network Integration
Integrates seamlessly into SIMATIC S7-300 automation architectures and industrial control systems.
Compared to other compact PLC processors with similar functionality, the Siemens 6ES7314-6BH04-0AB0 offers the advantage of integrated I/O resources, built-in point-to-point communication, and seamless compatibility with the SIMATIC S7-300 platform. These features provide a more compact, flexible, and cost-efficient automation solution while maintaining the performance and reliability required for industrial control applications.
The Siemens 6ES7314-6BH04-0AB0 CPU 314C-2 PTP Compact CPU delivers dependable processing performance for machine and process automation applications. Its integrated architecture combines CPU functionality, communication capabilities, and I/O processing into a single compact unit, reducing system complexity while improving operational efficiency.
Operating at 24 V DC with a typical power loss of 13 W, the CPU balances processing capability and energy efficiency for continuous industrial use. The integrated PTP communication interface enables direct connectivity to external devices without requiring additional communication hardware, improving system responsiveness and reducing implementation costs. Combined with its ability to maintain operation during short power interruptions through a 5 ms stored energy reserve, the 6ES7314-6BH04-0AB0 provides reliable and efficient performance for demanding automation environments.
