Siemens 6ES7314-6CG03-0AB0 SIMATIC S7-300 CPU 314C-2 DP Compact CPU Ready For Ship

Siemens 6ES7314-6CG03-0AB0 SIMATIC S7-300 CPU 314C-2 DP Compact CPU Ready For Ship

Product Name:SIMATIC S7-300 CPU 314C-2 DP Compact CPU

Brand Name:Siemens

Model Number:6ES7314-6CG03-0AB0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7314 6cg03 0ab0 simatic s7 300 cpu 314c 2 dp compact cpu ready for ship-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7314-6CG03-0AB0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7314-6CG03-0AB0
Product Series	SIMATIC S7-300 CPU 314C-2 DP
Product Type	Compact Central Processing Unit (CPU)
Working Memory	96 KB integrated
Digital Inputs	24 DI
Digital Outputs	16 DO
Analog Inputs	4 AI + 1 Pt100 temperature input
Analog Outputs	2 AO
High-Speed Counters	4 channels, up to 60 kHz
Communication Interfaces	Integrated MPI + PROFIBUS DP
Supply Voltage	24 VDC (20.4–28.8 VDC)
Load Memory	Micro Memory Card (MMC), up to 8 MB
Programming Software	STEP 7 V5.3 SP2 or later
Dimensions	120 × 125 × 130 mm
Weight	Approx. 676 g

Description

The 6ES7314-6CG03-0AB0 is a high-performance SIMATIC S7-300 CPU 314C-2 DP Compact CPU engineered for medium-sized industrial automation systems requiring integrated digital and analog I/O together with reliable PROFIBUS communication. Compared with standard CPUs such as 6ES7313-5BF03-0AB0 and 6ES7315-2EH14-0AB0, this model combines onboard control functions, distributed I/O support, and advanced motion capabilities within a compact housing.

Designed for demanding automation environments, the 6ES7314-6CG03-0AB0 provides 24 digital inputs, 16 digital outputs, 4 analog inputs, 2 analog outputs, one Pt100 temperature input, and four 60 kHz high-speed counters. Its integrated MPI and PROFIBUS DP interfaces simplify communication with remote I/O, HMIs, and field devices while reducing additional hardware requirements.

With 96 KB integrated work memory, Micro Memory Card support up to 8 MB, high-speed processing, and comprehensive STEP 7 programming compatibility, the 6ES7314-6CG03-0AB0 delivers dependable performance for machine automation, production lines, process control, packaging equipment, and factory modernization projects where stability, flexibility, and long service life are essential.

Applications

Power plants: Used for turbine auxiliary control, generator monitoring, and distributed automation systems requiring reliable real-time data processing.
Substations: Enable PROFIBUS communication, protection signal collection, equipment status monitoring, and intelligent switchgear control.
Chemical plants: Integrate process automation, analog signal acquisition, temperature monitoring, and continuous production control.
Steel mills: Execute high-speed logic control, equipment sequencing, and production monitoring in environments with vibration and electromagnetic interference.
Machinery manufacturing: Operate automated assembly lines, robotic cells, packaging equipment, conveyors, and precision manufacturing systems.
Water treatment plants: Control pumps, valves, instrumentation, and distributed field devices for stable plant operation.
Food & beverage industry: Coordinate production equipment, filling machines, material handling, and quality monitoring systems.

Features

Integrated 24 DI, 16 DO, 4 AI, 2 AO, and Pt100 input
Built-in MPI and PROFIBUS DP communication
Four 60 kHz high-speed counters for motion applications
96 KB integrated work memory with MMC expansion
Compact S7-300 design for space-saving installations
Compatible with STEP 7 engineering software
Fast instruction execution for real-time control
Industrial-grade reliability for continuous operation

Functions

Executes PLC logic and sequential machine control
Collects digital, analog, and temperature signals simultaneously
Communicates with distributed I/O through PROFIBUS DP
Supports high-speed counting, frequency measurement, and positioning
Performs PID process control for industrial automation
Coordinates HMI, drives, sensors, and actuators efficiently
Stores application programs and data using Micro Memory Cards
Provides stable communication for integrated production systems

FAQ

Q1: What is the 6ES7314-6CG03-0AB0 mainly used for?
A1: It is designed for medium-sized industrial automation systems requiring integrated I/O and PROFIBUS DP communication.

Q2: Does the 6ES7314-6CG03-0AB0 include onboard analog I/O?
A2: Yes. It features 4 analog inputs, 2 analog outputs, and one integrated Pt100 temperature input.

Q3: What communication interfaces are available?
A3: The CPU includes one integrated MPI interface and one PROFIBUS DP interface for industrial networking.

Q4: Can this CPU perform high-speed counting applications?
A4: Yes. It provides four integrated high-speed counters supporting frequencies up to 60 kHz for motion and positioning tasks.

Q5: Which programming software supports the 6ES7314-6CG03-0AB0?
A5: It is programmed using Siemens STEP 7 V5.3 SP2 or later with the appropriate hardware updates.
