Product Name:SIMATIC S7-300, CPU 314C-2 DP Compact CPU with MPI
Brand Name:Siemens
Model Number: 6ES7314-6CH04-0AB0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7314-6CH04-0AB0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Product Model | 6ES7314-6CH04-0AB0 |
| CPU Type | S7-300 CPU 314C-2 DP |
| Supply Voltage | 24 V DC (19.2–28.8 V) |
| Work Memory | 192 KB |
| Load Memory | Micro Memory Card (up to 8 MB) |
| Digital Inputs | 24 DI |
| Digital Outputs | 16 DO (4 high-speed up to 2.5 kHz) |
| Analog Inputs | 4 AI + 1 Pt100 |
| Analog Outputs | 2 AO |
| Communication | MPI / PROFIBUS DP (RS485) |
| Protection Class | IP20 |
| Dimensions | 120 × 125 × 130 mm |
| Weight | Approx. 680 g |
The 6ES7314-6CH04-0AB0 is a SIMATIC S7-300 CPU 314C-2 DP compact controller designed for advanced automation tasks with integrated I/O and communication functions. It combines digital and analog processing capabilities, including 24 DI, 16 DO, 4 AI, and 2 AO channels, along with high-speed counters and built-in technology functions.
Engineered with an integrated PROFIBUS DP interface, the 6ES7314-6CH04-0AB0 enables seamless communication in distributed control systems. Its 192 KB work memory and Micro Memory Card support ensure flexible program handling and reliable data storage without battery dependency.
With compact integration of control, motion, and process functions, this CPU is ideal for space-saving automation solutions requiring high performance, diagnostics, and real-time control.
Q1: What is the main function of 6ES7314-6CH04-0AB0?
A1: It is a compact PLC CPU used for controlling automation systems with integrated I/O and PROFIBUS DP communication.
Q2: Does this CPU support analog signals?
A2: Yes, it includes 4 analog inputs, 2 analog outputs, and 1 Pt100 input.
Q3: What communication interfaces are available?
A3: It supports MPI and PROFIBUS DP via integrated RS485 interfaces.
Q4: Can it handle high-speed applications?
A4: Yes, it supports high-speed counters up to 60 kHz and fast pulse outputs.
Q5: Is external battery required for memory backup?
A5: No, program and data backup are maintained via Micro Memory Card.
|
