Product Name: CPU315F-2 PN/DP Central Processing Unit
Brand Name: Siemens
Model Number: 6ES7315-2FJ14-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7315-2FJ14-0AB0 CPU315F-2 PN/DP Central Processing Unit |
| Manufacturer | Siemens |
| Product Type | CPU315F-2 PN/DP Central Processing Unit |
| Part Number | 6ES7315-2FJ14-0AB0 |
| Weight | 0.34kg |
| Estimated shipping dimensions | 4x12.3x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Firmware version | V3.2 |
| Rated value (DC) | 24 V |
| Supply voltage permissible range | 20.4 V- 28.8 V |
| Inrush current, typ. | 4 A |
| I²t | 1 A²·s |
| Power loss, typ. | 4.65 W |
| Work memory integrated | 512 kbyte |
| Number of blocks (total) | 1024; (DBs, FCs, FBs); the maximum number of loadable blocks can be reduced by the MMC used. |
| Retentive data area (incl. timers, counters, flags), max. | 128 kbyte |
| Number of expansion units, max. | 3 |
| Interface type Integrated RS | 485 interface |
| Isolated | Yes |
| Transmission rate, max. | 12 Mbit/s |
| Output current of the interface, max. | 200 mA |
The Siemens 6ES7315-2FJ14-0AB0 CPU315F-2 PN/DP Central Processing Unit is a high-performance fail-safe PLC processor designed for advanced industrial automation and safety-critical applications. As part of the SIMATIC S7-300 family, it combines standard control functions with integrated safety capabilities, enabling reliable execution of both automation and safety-related tasks within a single controller.
The CPU315F-2 PN/DP is particularly suited for applications requiring high system availability, personnel protection, and process safety. It supports communication across industrial networks while providing the processing power needed for machine control, manufacturing systems, and complex process automation environments.
Fail-Safe Control Processing
Executes both standard automation logic and safety-related control functions within a single controller.
Automation Program Execution
Processes user-defined control programs for machine, process, and manufacturing automation.
Industrial Communication Management
Supports high-speed data exchange through integrated communication interfaces and network connectivity.
Safety Monitoring & Protection
Monitors safety devices and executes safety functions to protect personnel, equipment, and processes.
Data Storage & Retention
Maintains critical operational data using retentive memory areas during power interruptions.
System Expansion Management
Coordinates communication and operation of connected expansion modules and distributed devices.
Diagnostics & System Monitoring
Provides advanced diagnostic functions to simplify maintenance and fault detection.
Compared to other fail-safe PLC processors with similar functionality, the Siemens 6ES7315-2FJ14-0AB0 offers superior integration of safety and standard control functions, larger memory resources, and efficient communication capabilities. These advantages make it a highly reliable and cost-effective solution for industrial applications that require both advanced automation and functional safety in a single platform.
The Siemens 6ES7315-2FJ14-0AB0 CPU315F-2 PN/DP Central Processing Unit delivers high-speed and reliable processing performance for both standard automation and fail-safe control applications. With 512 KB of integrated work memory and support for up to 1024 program blocks, it efficiently executes complex control algorithms, safety functions, and communication tasks. The integrated isolated RS-485 interface supports transmission rates of up to 12 Mbit/s, ensuring fast and dependable data exchange across industrial networks, while the 128 KB retentive memory helps preserve critical operational data during power interruptions.
Despite its advanced processing and safety capabilities, the CPU315F-2 PN/DP maintains low power dissipation of just 4.65 W, providing an efficient balance of performance, reliability, and energy consumption for demanding industrial automation environments.
