Siemens 6ES7331-1KF01-0AB0 SIMATIC S7-300 SM331 Analog Input Module

Siemens 6ES7331-1KF01-0AB0 SIMATIC S7-300 SM331 Analog Input Module

Product Name: SIMATIC S7-300 SM331 Analog Input Module

Brand Name: Siemens

Model Number: 6ES7331-1KF01-0AB0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7331 1kf01 0ab0 simatic s7 300 sm331 analog input module-1

Overview
Product Parameters
Commercial Terms
Contact Us
Why Choose US
Major Business
Product Feature
FAQ
Recommended Products

Overview

The Siemens 6ES7331-1KF01-0AB0 SIMATIC S7-300 SM331 Analog Input Module is an 8-channel analog input module designed for the SIMATIC S7-300 PLC platform. It supports a wide variety of analog signal types, including voltage, current, resistance, and temperature sensors, making it suitable for diverse industrial measurement applications. Featuring 13-bit resolution, optical isolation, and integrating measurement technology, the module ensures accurate signal acquisition, excellent noise immunity, and reliable operation in demanding industrial automation environments.

Product Parameters

Product Name	Siemens 6ES7331-1KF01-0AB0 SIMATIC S7-300 SM331 Analog Input Module
Manufacturer	Siemens
Product Type	SIMATIC S7-300 SM331 Analog Input Module
Part Number	6ES7331-1KF01-0AB0
Place of shipment	Xiamen, China
Country of origin	Germany
Input Channels	8 Analog Inputs
Isolation	Optically Isolated
Resolution	13-bit (Including Sign, Overrange)
Measurement Principle	Integrating
Module Update Time	66 ms (50 Hz), 55 ms (60 Hz)
Integration Time	Parameterizable, 50 ms / 60 ms
Interference Suppression	50 Hz / 60 Hz
Backplane Bus Current	Max. 90 mA at 5 V DC
Typical Power Dissipation	0.4 W
Isolation Voltage	500 V DC
Required Front Connector	40-pin Front Connector
Voltage Input Range	±10 V, ±1 V, 0–10 V, 1–5 V
Voltage Input Resistance	100 kΩ
Current Input Range	0–20 mA, 4–20 mA, ±20 mA
Current Input Resistance	50 Ω
Resistance Measurement Range	0–6 kΩ, 0–600 kΩ
Temperature Sensor Support	Pt100, Ni100, Ni1000, LG-Ni1000
Maximum Voltage (Destruction Limit)	30 V (12 V Continuous, 30 V for 1 s Max.)
Maximum Current (Destruction Limit)	40 mA
Voltage Accuracy	±0.5% to ±0.6% of Full Scale
Current Accuracy	±0.5% of Full Scale
Resistance Accuracy	±0.5% of Full Scale
Temperature Measurement Accuracy	±1 K (Typical), ±1.2 K (Standard Pt100/Ni100)

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Us

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Why Choose US

✔ Genuine Industrial Automation Products
✔ Strict Quality Inspection Before Shipment
✔ Competitive Prices & Flexible Quotations
✔ Large Inventory with Fast Global Shipping
✔ 12-Month Warranty on Eligible Products
✔ Professional Technical & After-Sales Support
✔ Inquiry Response Within 1 Hour
✔ Secure Packaging for International Shipping
✔ Trusted Supplier for PLC, DCS, HMI, and Industrial Control Systems

Major Business

ABB: Industrial robot parts of DSQC series,Bailey INFI90, DCS
Honeywell: 51/MU/MC/TC/CC ...
Triconex: 3008/3511/3625/3664/3721/3700A..
Bently Nevada: 3500/3300/330180-Cable..
Foxboro: FBM203/204/217/231, FCP240/270
Woodward: SPC valve position controller, PEAK15 digital controller
Siemens: 6DD/6DP/6ES5/6DR/6GK Series
Westinghouse Series: 1C/5X ...
General electric: IC693/IC697/IC695/DS200..
Schneider: 140 Series

Product Feature

8 Analog Input Channels
Supports eight independent analog input channels for efficient multi-signal acquisition.
Multiple Signal Types Supported
Accepts voltage, current, resistance, and RTD temperature sensor inputs, providing exceptional application flexibility.
High Measurement Accuracy
Delivers 13-bit resolution with high measurement precision for reliable process monitoring and control.
Optical Isolation Protection
Provides optical isolation between field signals and the PLC backplane to improve system safety and reduce electrical interference.
Excellent Noise Suppression
Supports selectable 50 Hz or 60 Hz interference suppression for stable signal measurement in noisy industrial environments.
Wide Sensor Compatibility
Compatible with Pt100, Ni100, Ni1000, and LG-Ni1000 temperature sensors for versatile temperature monitoring.
Flexible Parameter Configuration
Allows configurable integration times and measurement parameters to optimize performance for different applications.
Reliable Industrial Design
Features low power consumption, high isolation voltage, and robust construction for continuous industrial operation.

FAQ

---What is the 6ES7331-1KF01-0AB0 used for?
6ES7331-1KF01-0AB0 is used to acquire analog signals from field devices and transmit measurement data to a SIMATIC S7-300 PLC.

---How many analog input channels does the 6ES7331-1KF01-0AB0 provide?
6ES7331-1KF01-0AB0 provides eight analog input channels.

---What types of input signals does the 6ES7331-1KF01-0AB0 support?
6ES7331-1KF01-0AB0 supports voltage, current, resistance, and RTD temperature sensor inputs.

---What is the resolution of the 6ES7331-1KF01-0AB0?
6ES7331-1KF01-0AB0 features 13-bit resolution, including sign and overrange detection.

---Which temperature sensors are compatible with the 6ES7331-1KF01-0AB0?
6ES7331-1KF01-0AB0 supports Pt100, Ni100, Ni1000, and LG-Ni1000 temperature sensors.

---Does the 6ES7331-1KF01-0AB0 provide electrical isolation?
6ES7331-1KF01-0AB0 provides optical isolation with an isolation voltage of 500 V DC to improve system reliability.
