Product Name: Communications Processor
Brand Name: Siemens
Model Number: 6ES7341-1CH01-0AE0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
||
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6ES7341-1CH01-0AE0 Communications Processor |
| Manufacturer | Siemens |
| Product Type | Communications Processor |
| Part Number | 6ES7341-1CH01-0AE0 |
| Weight | 0.3kg |
| Estimated shipping dimensions | 4x11.7x12.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Rated value (DC) | 24 V DC |
| from supply voltage L+, max. | 240 mA |
| from backplane bus 5 V DC, max. | 70 mA |
| Power loss, max. | 5.8 W |
| Number of interfaces | 1; Isolated |
| Transmission rate, min. | 0.3 kbit/s |
| Transmission rate, max. | 76.8 kbit/s |
| Connector type | 15-pin sub D connector |
| Power supply | 3 screw-type terminals: L+, M, GND |
The Siemens 6ES7341-1CH01-0AE0 is a communications processor designed for the SIMATIC S7-300 automation platform, providing reliable serial communication between PLC systems and external devices. Equipped with an isolated communication interface, it enables secure and stable data exchange in industrial environments where dependable connectivity is essential for machine control, process automation, and system integration.
The Siemens 6ES7341-1CH01-0AE0 supports configurable serial communication with transmission speeds ranging from 0.3 kbit/s to 76.8 kbit/s. Featuring a 15-pin D-sub connector and robust electrical isolation, it is ideal for connecting PLCs to HMIs, barcode readers, printers, weighing systems, and other industrial communication devices while maintaining high signal integrity and operational reliability.
The primary function of the Siemens 6ES7341-1CH01-0AE0 is to provide dedicated serial communication capabilities for S7-300 PLC systems, enabling efficient data exchange with external equipment.
Key functions include:
Compared with standard serial communication modules, the Siemens 6ES7341-1CH01-0AE0 offers enhanced reliability, seamless S7-300 integration, and superior industrial communication performance.
1. Native S7-300 Compatibility
The Siemens 6ES7341-1CH01-0AE0 integrates directly into Siemens S7-300 systems, minimizing engineering effort and ensuring reliable operation.
2. Isolated Communication Interface
Unlike many basic communication modules, the Siemens 6ES7341-1CH01-0AE0 provides electrical isolation to protect connected equipment from electrical disturbances and ground loops.
3. Reliable Industrial Communication
Designed specifically for industrial environments, it delivers more stable communication performance than generic serial converters.
4. Flexible Device Connectivity
The Siemens 6ES7341-1CH01-0AE0 can communicate with a wide range of industrial devices, making it suitable for diverse automation applications.
5. Robust Electrical Design
Industrial-grade protection and stable power management enhance operational reliability compared with commercial communication interfaces.
6. Reduced System Complexity
By providing dedicated communication processing within the PLC architecture, the Siemens 6ES7341-1CH01-0AE0 helps simplify system integration and maintenance.
Q1: What is the primary purpose of Siemens 6ES7341-1CH01-0AE0?
A: The Siemens 6ES7341-1CH01-0AE0 is used to provide serial communication capabilities for S7-300 PLC systems and connect them to external industrial devices.
Q2: Does 6ES7341-1CH01-0AE0 have an isolated communication interface?
A: Yes, the Siemens 6ES7341-1CH01-0AE0 features an isolated interface that helps improve communication reliability and protects connected equipment.
Q3: What communication speed does 6ES7341-1CH01-0AE0 support?
A: The Siemens 6ES7341-1CH01-0AE0 supports configurable transmission rates from 0.3 kbit/s up to 76.8 kbit/s.
Q4: What connector type is used on 6ES7341-1CH01-0AE0?
A: The Siemens 6ES7341-1CH01-0AE0 is equipped with a 15-pin D-sub connector for industrial communication connections.
Q5: What devices can be connected to 6ES7341-1CH01-0AE0?
A: The Siemens 6ES7341-1CH01-0AE0 can be connected to HMIs, barcode scanners, printers, weighing systems, and other serial communication devices.
