Siemens 6ES7350-1AH03-0AE0 Counter module FM 350-1 for S7-300 In stock

Siemens 6ES7350-1AH03-0AE0 Counter module FM 350-1 for S7-300 In stock

Product Name:Counter module FM 350-1 for S7-300

Brand Name:Siemens

Model Number:6ES7350-1AH03-0AE0

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6es7350 1ah03 0ae0 counter module fm 350 1 for s7 300 in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Features
Functions
FAQ
Spares
Recommended Products

Overview

Brand Name:	Siemens
Model Number:	6ES7350-1AH03-0AE0
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6ES7350-1AH03-0AE0
Manufacturer	Siemens
Product Series	SIMATIC S7-300
Product Type	Counter Module FM 350-1
Counter Channels	1 channel
Max Counting Frequency	500 kHz (5 V), 200 kHz (24 V)
Encoder Support	5 V / 24 V incremental encoders
Input Type	RS422 / differential / 24 V input
Digital Inputs	3 (gate start/stop/reset)
Digital Outputs	2
Encoder Supply	5 V / 24 V integrated
Power Supply	24 V DC
Backplane Current	Max. 160 mA
Power Loss	Approx. 4.5 W
Isolation	Optocoupler, 500 V DC
Dimensions	40 × 125 × 120 mm
Weight	approx. 0.25 kg

Description

The Siemens 6ES7350-1AH03-0AE0 is a high-performance FM 350-1 counter module designed for SIMATIC S7-300 automation systems. It enables precise high-speed counting and signal processing for industrial motion and position measurement applications.

The 6ES7350-1AH03-0AE0 supports a single high-speed counter channel with frequencies up to 500 kHz and is compatible with both 5 V and 24 V incremental encoders. It features optically isolated inputs and outputs, ensuring stable operation in electrically noisy industrial environments. With integrated encoder power supply options and configurable measuring functions, it provides flexible and accurate motion tracking.

As part of the Siemens S7-300 platform, the 6ES7350-1AH03-0AE0 is widely used in automation systems requiring precise speed measurement, position detection, and high-speed pulse counting in demanding industrial conditions.

Applications

Power Plants: Used for turbine speed monitoring, generator synchronization, and protection systems.
Substations: Enables high-speed signal acquisition, switching control, and protection measurement.
Chemical Plants: Supports precise process monitoring, flow measurement, and automation control.
Steel Mills: Ensures reliable operation under high EMI and temperature environments for motion tracking systems.
Machinery Manufacturing Plants: Used in CNC machines, robotics, and automated production lines.
Oil & Gas Facilities: Supports pipeline monitoring, valve positioning, and rotational speed measurement.
Water Treatment Plants: Used for pump speed monitoring, flow control, and process automation systems.

Features

Single-channel high-speed counter module
Supports up to 500 kHz counting frequency
Compatible with 5 V and 24 V incremental encoders
Integrated encoder power supply (5 V / 24 V)
Optically isolated input/output design
Flexible gate and reset input functions
Compact S7-300 module format
Designed for high-speed industrial motion control

Functions

Performs high-speed pulse counting
Measures rotational speed and position
Processes encoder signals in real time
Supports gate control and counter reset functions
Provides precise motion tracking data
Ensures stable signal isolation and processing
Integrates with S7-300 automation systems

FAQ

Q1: What is the main function of Siemens 6ES7350-1AH03-0AE0?
A1: It is a high-speed counter module used for position and speed measurement in automation systems.

Q2: What is the maximum counting frequency?
A2: It supports up to 500 kHz for 5 V encoders.

Q3: Does it support both 5 V and 24 V encoders?
A3: Yes, it supports both incremental encoder types.

Q4: How many counter channels are available?
A4: It provides 1 high-speed counter channel.

Q5: Where is this module commonly used?
A5: It is used in motion control, CNC systems, and industrial automation lines.
