Home > Products > SIEMENS > SIMATIC S7 Series
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Model Number
|
6ES7414-2XG03-0AB0
|
|
Integrated work memory
|
256 kbyte total
|
|
Program work memory
|
128 kbyte for code
|
|
Data work memory
|
128 kbyte for data
|
|
Integrated RAM load memory
|
256 kbyte RAM
|
|
Maximum FLASH load-memory expansion
|
64 Mbyte with FLASH Memory Card
|
|
Maximum RAM load-memory expansion
|
64 Mbyte with RAM Memory Card
|
|
Typical backplane current at 5 V DC
|
1.5 A
|
|
Maximum backplane current at 5 V DC
|
1.6 A
|
|
Maximum interface current at 24 V DC
|
300 mA total; maximum 150 mA per MPI/DP interface
|
|
Typical power loss
|
7.5 W
|
|
External backup-voltage input
|
5–15 V DC
|
|
Backup current
|
40 µA typical; 380 µA maximum
|
|
Typical bit-operation time
|
0.1 µs per bit operation
|
|
Typical word-operation time
|
0.1 µs per word operation
|
|
Typical fixed-point arithmetic time
|
0.1 µs per fixed-point operation
|
|
Typical floating-point arithmetic time
|
0.6 µs
|
|
Maximum data blocks
|
4095 DBs; DB 0 reserved
|
|
Maximum function blocks
|
2048 FBs
|
|
Maximum functions
|
2048 FCs
|
|
Maximum block size
|
64 kbyte per DB / FB / FC / OB
|
|
Nesting depth
|
24 per priority class; two additional levels in an error OB
|
|
S7 counters
|
256 counters
|
|
S7 timers
|
256 timers; range 10 ms–9990 s
|
|
Flag memory
|
8 kbyte
|
|
I/O address area
|
8 kbyte inputs and 8 kbyte outputs
|
|
Default process image
|
256 input bytes and 256 output bytes
|
|
Maximum consistent process-image data
|
244 bytes
|
|
Maximum subprocess images
|
8 images
|
|
Maximum expansion units
|
21 units, including six ERs with K-bus
|
|
Maximum MPI transmission rate
|
12 Mbit/s
|
|
DP master slave capacity
|
First interface: 32 slaves; second interface: 96 slaves
|
|
First DP master address area
|
2 kbyte inputs and 2 kbyte outputs
|
|
Second DP master address area
|
6 kbyte inputs and 6 kbyte outputs
|
|
Diagnostic buffer
|
Up to 400 entries, adjustable
|
|
Sales
Jim Pei
|
Email
|
Phone/Whatsapp
|
Siemens 6ES7414-2XG03-0AB0 is the SIMATIC S7-400 CPU 414-2 processor module. It contains 256 kbyte of work memory divided between program code and data. The first communication interface provides MPI/PROFIBUS DP connectivity. A second dedicated PROFIBUS DP interface supports an additional fieldbus connection. This rack-based CPU executes the configured automation program within a compatible S7-400 station.
The processor supports the documented STEP 7 programming and commissioning functions. Its communication services connect the controller with suitable operator stations and distributed automation devices. Battery-backed retention preserves the documented working and load-memory data. Compatible RAM and FLASH Memory Cards provide the specified load-memory expansion options. Replacement planning should check the installed project, memory-card type and interface configuration against the complete order number.
|
