Product Name: SIMATIC S7-400 CPU 414-3
Brand Name: Siemens
Model Number: 6ES7414-3XJ04-0AB0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6ES7414-3XJ04-0AB0 |
| Power loss, typ. | 4.5 W |
| integrated | 1.4 Mbyte |
| integrated (for program) | 700 kbyte |
| integrated (for data) | 700 kbyte |
| integrated RAM, max. | 256 kbyte |
| Backup current, typ. | 550 µA |
| Backup current, max. | 1 530 µA |
| Feeding of external backup voltage to CPU | 5 V DC to 15 V DC |
| Resolution | 1 ms |
| Range of values | 0 to 32767 hours |
| Power supply to interface (15 to 30 V DC), max. | 150 mA |
| Transmission rate, max. | 12 Mbit/s |
| max. cycle | 32 ms |
| Firmware version | V4.0 |
| Programming package | STEP 7 V5.2 SP1 HF3 or higher with HW update |
| CiR synchronization time, basic load | 100 ms |
| CiR synchronization time, time per I/O byte | 80 µs |
| from backplane bus 5 V DC, typ. | 1A |
| from backplane bus 5 V DC, max. | 1.2 A |
| expandable FEPROM, max. | 64 Mbyte |
| expandable RAM, max. | 16 Mbyte |
| for bit operations, typ. | 0.06 µs |
| for word operations, typ. | 0.06 µs |
| for fixed point arithmetic, typ. | 0.06 µs |
| for floating point arithmetic, typ. | 0.18 µs |
| Number, max. | 4 095; DB 0 reserved |
| Size, max. | 64 kbyte |
| Number of clock memories | 8; 1 memory byte |
| adjustable, max. | 16 kbyte |
| Inputs | 8 kbyte |
| Outputs | 8 kbyte |
| Inputs, adjustable | 8 kbyte |
| Outputs, adjustable | 8 kbyte |
| Inputs, default | 256 byte |
|
01
The 6ES7414-3XJ04-0AB0 is used in manufacturing lines, material-handling systems, process plants, utilities, building infrastructure, and large machine-control installations where coordinated PLC operation is required. |
02
It is also suitable for maintenance projects, control-system expansion, replacement of installed S7-400 CPUs, modernization planning, and long-term spare-parts support for facilities that depend on established SIMATIC automation platforms. |
|
Q · How is the product packaged?
A · Original new Factory Sealed. |
Q · What is the delivery time?
A · Normally 3–7 days. Goods are dispatched promptly after payment is received. |
|
Q · Which payment terms are accepted?
A · T/T. |
Q · Which shipping methods are available?
A · DHL / FedEx / UPS / TNT. |
|
Q · Is the item available?
A · Yes. Supply Ability: In stock. |
Q · How do you ensure product quality?
A · The product is carefully checked before delivery and is supplied with quality-focused after-sales support. |
