Product Name: SIMATIC S7-400 FM 450-1 High-Speed Counter Function Module
Brand Name: Siemens
Model Number: 6ES7450-1AP00-0AE0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
| Product Name | Siemens 6ES7450-1AP00-0AE0 SIMATIC S7-400 FM 450-1 High-Speed Counter Function Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC S7-400 FM 450-1 High-Speed Counter Function Module |
| Part Number | 6ES7450-1AP00-0AE0 |
| Weight | 0.64kg |
| Estimated shipping dimensions | 29x22.2x2.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Number of Channels | 2 |
| Rated Supply Voltage | 24 V DC |
| Permissible Supply Voltage | 20.4–28.8 V DC (Dynamic: 18.5–30.2 V DC) |
| Reverse Polarity Protection | Yes |
| Input Current (Load Voltage) | Max. 40 mA |
| Backplane Bus Current | Max. 450 mA @ 5 V DC |
| Encoder Supply | 5.2 V DC (±2%), 24 V DC |
| Encoder Supply Output Current | Max. 300 mA |
| Encoder Supply Protection | Short-circuit Protected |
| Power Dissipation | Typical 9 W |
| Digital Inputs | 6 |
| Digital Outputs | 6 |
| Digital Input Frequency | Max. 200 kHz |
| Digital Input Current | Typical 9 mA |
| Digital Output Current | 0.5 A nominal, 0.6 A max. |
| Digital Output Delay | Max. 300 µs |
| Counter Inputs | 2 (32-bit or ±31-bit) |
| Counter Input Type | RS-422 Differential, 24 V |
| Maximum Counting Frequency | 500 kHz (RS-422), 200 kHz (24 V) |
| Minimum Pulse Width | ≥2.5 µs (200 kHz), ≤25 µs (20 kHz, parameterizable) |
| Status Indicators | 14 Green LEDs |
| Address Space | 64 Bytes Input / 64 Bytes Output |
| Isolation Voltage | 500 V Tested |
| Permissible Potential Difference | 75 V DC / 60 V AC |
| Front Connector | 1 × 48-pin Front Connector |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
The Siemens 6ES7450-1AP00-0AE0 SIMATIC S7-400 FM 450-1 High-Speed Counter Function Module is a dual-channel high-speed counter function module designed for SIMATIC S7-400 PLC systems. It provides accurate pulse acquisition and motion-related signal processing for demanding industrial automation applications. Supporting RS-422 differential and 24 V counter inputs, the module achieves counting frequencies of up to 500 kHz, making it ideal for encoder feedback, position tracking, speed monitoring, and event counting. It features six digital inputs, six digital outputs, integrated 5.2 V and 24 V encoder power supplies, and comprehensive diagnostic LEDs for reliable operation. With high-speed performance, electrical isolation, and seamless integration into the S7-400 platform, it is an ideal solution for precision motion control and industrial automation applications.
Dual High-Speed Counter Channels
Provides two independent high-speed counter channels supporting 32-bit or ±31-bit counting for precise motion and process control.
High-Frequency Pulse Processing
Supports counting frequencies up to 500 kHz with RS-422 differential inputs and 200 kHz with 24 V inputs for demanding encoder applications.
Multiple Encoder Interface Options
Compatible with both RS-422 differential and 24 V pulse encoders, offering flexible connectivity for various industrial sensors.
Integrated Encoder Power Supply
Supplies 5.2 V DC and 24 V DC encoder power with up to 300 mA output current and built-in short-circuit protection.
Comprehensive Digital I/O
Equipped with six digital inputs and six digital outputs for trigger, gate, comparison, and control functions within automation systems.
Fast Response Performance
Delivers digital output switching delays of up to 300 μs, ensuring rapid response in high-speed control applications.
Reliable Industrial Protection
Features reverse polarity protection, 500 V tested electrical isolation, and supports permissible potential differences up to 75 V DC / 60 V AC for enhanced operational reliability.
Advanced Diagnostics and Easy Integration
Includes 14 green LED status indicators, a 48-pin front connector, and 64-byte input/output address space for simplified installation, diagnostics, and maintenance within SIMATIC S7-400 systems.
