Marshalled termination assembly for redundant ET 200M fail-safe digital inputs with individually fused field channels.
Sales |
Jim Pei |
Email |
|
Phone/Whatsapp |
|
Model Number
|
6ES7650-1AK11-7XX0
|
|
Nominal field voltage
|
24 V DC
|
|
Power input range
|
21.6–28.8 V DC
|
|
Fail-safe input configuration
|
12 / 24 channels
|
|
Maximum current, all inputs at +24 V
|
1.482 A
|
|
Maximum current, all inputs at 0 V
|
1.002 A
|
|
Typical power dissipation
|
3 W
|
|
Individual channel fuse
|
0.05 A
|
|
Power wiring cross-section
|
0.205–2.08 mm²
|
|
Field wiring cross-section
|
0.205–2.08 mm²
|
|
Horizontal ambient temperature
|
-25 to +70 °C
|
|
Vertical ambient temperature
|
-25 to +60 °C
|
|
Humidity range
|
5–95%, non-condensing
|
|
DIN rail requirement
|
35 mm, deep top-hat profile
|
|
1oo1 voting safety integrity capability
|
SIL 2, dependent on corresponding I/O module
|
|
1oo1 voting performance capability
|
PL d / Category 3
|
|
1oo2 voting safety integrity capability
|
SIL 3, dependent on corresponding I/O module
|
|
1oo2 voting performance capability
|
PL e / Category 4
|
|
Proof-test interval in safety data
|
20 years
|
|
Redundant power feeds
|
2
|
|
I/O module connections
|
2
|
|
Channel power circuits
|
24, individually fused
|
|
Input-power indication
|
Green LED for available supply
|
|
Module-power indication
|
Green LED for module supply
|
|
Channel-power indication
|
Green LED for sensor supply
|
|
Minimum Order Quantity
|
1 Piece
|
|
Price
|
Contact for Jim
|
|
Packaging Details
|
Original new Factory Sealed
|
|
Delivery Time
|
3–7 Days
|
|
Payment Terms
|
T/T
|
|
Shipping Method
|
DHL / FedEx / UPS / TNT
|
|
Supply Ability
|
In stock
|
Siemens 6ES7650-1AK11-7XX0 is a SIMATIC PCS 7 redundant fail-safe digital input marshalled termination assembly. It interfaces field wiring with the specified ET 200M fail-safe input module. Dual module connections support the redundant I/O arrangement. Field power is individually fused at the channel level. Local power indications help identify the supply condition during service.
The 6ES7650-1AK11-7XX0 organizes field termination in process control cabinets using the applicable ET 200M architecture. Pluggable terminations and channel disconnects support wiring maintenance. Redundant power feeds are combined within the termination arrangement. Achievable safety performance depends on the corresponding I/O module and voting configuration. Confirm the exact fuse specification, module revision and cabinet orientation before installation.
Connects field circuits to the specified ET 200M fail-safe input module.
Provides dual connections for the intended redundant module arrangement.
Organizes pluggable field terminations and channel disconnect points.
Power supervision — Local indicators show input, module and channel power availability.
Shield termination — Provides the specified shield and earth-ground connection arrangement.
Safety configuration — Select the I/O voting architecture against the required safety design.
No. It is the marshalled termination assembly connected to the specified fail-safe input module.
The product description identifies 6ES7326-1BK02-0AB0; check the required revision and system documentation.
No. Achievable safety class depends on the corresponding I/O module and voting configuration.
Yes. We can provide photographs and available condition checks for the offered item.
Confirmed in-stock items are arranged for dispatch immediately after payment.
Verify the exact article, fusing, connected modules and wiring arrangement before exchange.
