Product Name:Analog input module
Brand Name:Siemens
Model Number:6ES7650-8AR60-1AA0
Country of Origin:Germany
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6ES7650-8AR60-1AA0 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Model | 6ES7650-8AR60-1AA0 |
| Product Type | Analog input module (TC/RTD) |
| Input Channels | 8 channels |
| Signal Types | Thermocouple / RTD |
| Resolution | Up to 16-bit |
| System Compatibility | ET 200PA SMART / PCS 7 |
| Supply Voltage | 24 V DC system power |
| Current Consumption | Approx. 150 mA |
| Communication | Distributed I/O system integration |
| Dimension (W×H×D) | 45 × 120 × 75 mm |
| Weight | Approx. 180 g |
| Mounting Type | Rail-mounted I/O module |
| Isolation | Channel-to-system isolation |
| Operating Temp | Industrial-grade range |
The 6ES7650-8AR60-1AA0 is a multifunction analog input module designed for precise temperature and process signal acquisition in advanced distributed control systems. It supports both thermocouple (TC) and resistance temperature detector (RTD) inputs, enabling flexible integration in industrial monitoring applications.
As part of the Siemens Siemens ET 200PA SMART I/O family, this module is optimized for process automation environments requiring high accuracy, stable signal processing, and robust diagnostics. It is compatible with PCS 7 systems and supports modern plant-wide integration strategies for both standard and HART-enabled configurations.
The module is widely used in industrial automation networks where reliable temperature measurement, high noise immunity, and scalable I/O architecture are required.
Q1: What is 6ES7650-8AR60-1AA0 used for?
A1: It is used for acquiring and processing temperature signals from TC and RTD sensors in automation systems.
Q2: What types of sensors are supported?
A2: It supports thermocouples (TC) and resistance temperature detectors (RTD).
Q3: Is it compatible with PCS 7 systems?
A3: Yes, it is fully compatible with Siemens PCS 7 process automation systems.
Q4: How many input channels does it provide?
A4: The module provides 8 analog input channels.
Q5: Where is this module typically used?
A5: It is widely used in power plants, substations, and industrial process automation systems.
|
