Siemens 6ES7650-8EK70-0AA0 ET 200PA SMART Digital Output Module

Siemens 6ES7650-8EK70-0AA0 ET 200PA SMART Digital Output Module

Product Name: ET 200PA SMART Digital Output Module

Brand Name: Siemens

Model Number: 6ES7650-8EK70-0AA0

Place of Origin: Germany

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

siemens 6es7650 8ek70 0aa0 et 200pa smart digital output module-1

Overview
Specifications
Commercial Terms
Overview
Features
Product Applications
Why Choose US
Other Products
Recommended Products

Contact Info

Sales:	Email:	Whatsapp:
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Siemens 6ES7650-8EK70-0AA0 ET 200PA SMART Digital Output Module
Manufacturer	Siemens
Product Type	ET 200PA SMART Digital Output Module
Part Number	6ES7650-8EK70-0AA0
Place of shipment	Xiamen, China
Country of origin	Germany
Digital Outputs	16 × Digital Outputs
Output Type	24 V DC Transistor
Rated Output Current	0.5 A per channel
Output Voltage	24 V DC
Load Voltage (L+)	24 V DC
Short-Circuit Threshold	1.4 A (typical, per channel)
Lamp Load	Max. 5 W
Resistive Load Switching Frequency	Max. 100 Hz
Inductive Load Switching Frequency	Max. 2 Hz
Lamp Load Switching Frequency	Max. 10 Hz
Residual Current (Signal "0")	Max. 0.7 mA
Output Current Range	5 mA to 0.6 A
Output Voltage (Signal "1")	Min. L+ −1.3 V
Output Voltage (Signal "0")	Max. 31 V
Current Consumption (Load Voltage)	Max. 100 mA (without load)
Backplane Bus Current	Max. 100 mA @ 5 V DC
Typical Power Loss	6 W
Permissible Potential Difference	75 V DC / 60 V AC
Isolation Test Voltage	500 V AC / 707 V DC
Cable Length (Shielded)	Max. 1000 m
Cable Length (Unshielded)	Max. 600 m
Operating Temperature	Up to 60°C (horizontal), Up to 40°C (vertical)
Connection Method	1 × 40-pin front connector (IM 650-8PH required)
Required Interface Module	IM 650-8PH

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Overview

The Siemens 6ES7650-8EK70-0AA0 ET 200PA SMART Digital Output Module is a high-performance digital output module designed for the Siemens ET 200PA SMART distributed I/O system. Featuring 16 transistor digital outputs, the module delivers reliable 24 VDC switching for a wide range of industrial field devices. With integrated short-circuit protection, high output capacity, long cable support, and dependable industrial performance, it provides an efficient solution for distributed automation and machine control applications.

Features

Designed for Siemens ET 200PA SMART distributed I/O systems
Provides 16 transistor digital output channels
24 VDC digital output for industrial control applications
Rated output current of 0.5 A per channel
Output current range from 5 mA to 0.6 A
Integrated short-circuit protection with a typical threshold of 1.4 A per channel
Supports resistive, inductive, and lamp load switching
Maximum lamp load of 5 W per output
Switching frequencies up to 100 Hz for resistive loads
Low residual current when outputs are in the OFF state
Maximum load voltage current consumption of 100 mA without load
Typical power loss of 6 W
Electrical isolation with 500 VAC / 707 VDC isolation test voltage
Supports cable lengths up to 1000 m (shielded) and 600 m (unshielded)
Operates in industrial environments up to 60°C (horizontal installation)
Uses a 40-pin front connector and requires the IM 650-8PH interface module

Product Applications

The Siemens 6ES7650-8EK70-0AA0 digital output module is widely used in distributed industrial automation systems requiring reliable 24 VDC output control. Typical applications include manufacturing equipment, conveyor systems, packaging machinery, material handling systems, assembly lines, process automation, water treatment, HVAC systems, and factory automation.

The module is ideal for controlling relays, contactors, solenoid valves, indicator lamps, alarms, and other industrial actuators. As part of the ET 200PA SMART platform, it provides a flexible and dependable digital output expansion solution for OEM machinery, distributed control systems, and industrial applications requiring high-density I/O, reliable switching performance, and long-distance field wiring.
