Product Name: SIMATIC DP ET 200PA SMART IM 650-8 PH Interface Module
Brand Name: Siemens
Model Number: 6ES7650-8PH00-0AA0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6ES7650-8PH00-0AA0 SIMATIC DP ET 200PA SMART IM 650-8 PH Interface Module |
| Manufacturer | Siemens |
| Product Type | SIMATIC DP ET 200PA SMART IM 650-8 PH Interface Module |
| Part Number | 6ES7650-8PH00-0AA0 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Maximum Modules per DP Slave | 12 |
| Maximum Input Address Space | 244 Bytes |
| Maximum Output Address Space | 244 Bytes |
| Rated Supply Voltage | 24 V DC |
| Recommended External Protection | 2.5 A |
| Voltage Hold-Up Time | 5 ms |
| Maximum Current Consumption | 650 mA |
| Typical Inrush Current | 3 A |
| I²t Value | 0.1 A²·s |
| Backplane Bus Voltage | 5 V DC |
| Maximum Backplane Bus Output Current | 1.5 A |
| Typical Power Loss | 5.5 W |
| Time Stamp Accuracy | 1 ms (up to 8 modules), 10 ms (up to 12 modules) |
| Maximum Timestamped Digital Inputs | 128 |
| Maximum Signals per Slot | 32 |
| Message Buffers | 15 |
| Messages per Buffer | 20 |
| Time Resolution | 0.466 ns |
| Message Transmission Interval | 1000 ms |
| Communication Interface | RS-485 |
| Connector Type | 9-pin Sub-D |
| Maximum Interface Output Current | 70 mA |
| Maximum Transmission Rate | 12 Mbit/s |
| Isolation Voltage | 500 V |
| Operating Temperature (Horizontal) | 0°C to +60°C |
| Operating Temperature (Vertical) | 0°C to +40°C |
| Maximum Installation Altitude | 3000 m |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6ES7650-8PH00-0AA0 SIMATIC DP ET 200PA SMART IM 650-8 PH Interface Module is a PROFIBUS DP interface module designed for the ET 200PA SMART distributed I/O system. It supports up to 12 expansion modules, provides RS-485 communication with data rates up to 12 Mbit/s, and offers reliable high-speed data exchange with accurate time stamping. With stable 24 V DC operation and robust industrial performance, it is ideal for process automation and distributed control applications.
Compared with similar distributed I/O interface modules, the Siemens 6ES7650-8PH00-0AA0 provides greater expansion capability, precise synchronization, and reliable PROFIBUS communication.
Q1: What is the 6ES7650-8PH00-0AA0 used for?
A1: 6ES7650-8PH00-0AA0 is used as the PROFIBUS DP interface module for ET 200PA SMART distributed I/O systems.
Q2: How many expansion modules does the 6ES7650-8PH00-0AA0 support?
A2: 6ES7650-8PH00-0AA0 supports up to 12 expansion modules.
Q3: What communication interface does the 6ES7650-8PH00-0AA0 use?
A3: 6ES7650-8PH00-0AA0 uses an RS-485 interface with a 9-pin Sub-D connector.
Q4: What is the maximum communication speed of the 6ES7650-8PH00-0AA0?
A4: 6ES7650-8PH00-0AA0 supports PROFIBUS communication speeds up to 12 Mbit/s.
Q5: What power supply is required for the 6ES7650-8PH00-0AA0?
A5: 6ES7650-8PH00-0AA0 operates with a 24 V DC supply.
Q6: Does the 6ES7650-8PH00-0AA0 support time stamping?
A6: 6ES7650-8PH00-0AA0 supports high-accuracy time stamping with up to 1 ms precision.
