Siemens 6ES7655-5PX11-1AX0 SIMATIC CFU PA Bundle

The Siemens 6ES7655-5PX11-1AX0 is a SIMATIC CFU PA bundle supplied with an aluminum enclosure, cable glands, shield busbar and shield terminals. It combines fieldbus connectivity and configurable digital channels in a preassembled, factory-checked unit for process automation systems.

Commercial Term

Supply Ability

In stock

Price

Contact for Jim

Packaging Details

Original new Factory Sealed

Delivery Time

3–7 Days

Payment Terms

T/T

Shipping Method

DHL / FedEx / UPS / TNT

Specifications

Firmware version	V2.0
Vendor identification (VendorID)	002AH
Device identifier (DeviceID)	060DH
Number of channels	16
Rated supply voltage	24 V DC
Permissible supply voltage range	19.2–28.8 V DC
Mains buffering time	5 ms
Rated current consumption	2.5 A
Maximum current consumption	2.55 A
Maximum inrush current	8 A
I²t value	0.3 A²·s
Encoder supply outputs	8
Minimum encoder output voltage	18.2 V
Maximum encoder output current up to 60 °C	2 A
Maximum encoder output current up to 70 °C	1 A
Typical power loss	8.2 W
Maximum address space per station	1,440 bytes
Digital inputs	8
Maximum counters	1
Maximum counting frequency	1 kHz
Counting width	32 bit
Input voltage for signal 0	−30 to +5 V
Input voltage for signal 1	+11 to +30 V
Typical input current for signal 1	2.5 mA
Maximum input delay	3.2 ms
Digital outputs	8
Output short-circuit response threshold	0.7–1.3 A
Maximum lamp load	5 W
Load resistance range	48 Ω–12 kΩ
Rated output current for signal 1	0.5 A
Maximum residual current for signal 0	0.1 mA
Maximum output delay	50 µs on / 100 µs off
Maximum resistive switching frequency	100 Hz
Maximum inductive switching frequency	2 Hz
Maximum lamp-load switching frequency	10 Hz

Contact info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Description

6ES7655-5PX11-1AX0 is the Siemens SIMATIC CFU PA bundle designed for reliable integration of PROFIBUS PA field devices with PROFINET-based automation architectures. The unit provides configurable digital channels and robust field connectivity in a preassembled aluminum enclosure. Its official Siemens design supports structured diagnostics, commissioning and maintenance workflows. This Siemens SIMATIC CFU PA solution helps simplify distributed process instrumentation and control. It is suitable for lifecycle replacement, modernization and new process automation projects. Amikon supplies original industrial automation components with responsive commercial and technical support.

Function

Connects PROFIBUS PA field devices to a PROFINET automation network.

Provides configurable digital input and output channels for auxiliary field signals.

Supports commissioning and diagnostics of connected field devices.

Enables redundant power supply arrangements for higher availability.

Provides electronic short-circuit protection for field-side circuits.

Supports counter operation for suitable digital input applications.

Offers status indication for operating, maintenance and fault conditions.

Integrates with Siemens engineering environments for process automation projects.
