Product Name: SIMATIC NET IE/PB LINK PN IO Industrial Ethernet/PROFIBUS Gateway
Brand Name: Siemens
Model Number: 6GK1411-5AB10
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales |
Phone/Whatsapp |
|
Jim Pei |
| Product Name | Siemens 6GK1411-5AB10 SIMATIC NET IE/PB LINK PN IO Industrial Ethernet/PROFIBUS Gateway |
| Manufacturer | Siemens |
| Product Type | SIMATIC NET IE/PB LINK PN IO Industrial Ethernet/PROFIBUS Gateway |
| Part Number | 6GK1411-5AB10 |
| Weight | 0.25kg |
| Estimated shipping dimensions | 10x13x7.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Product Family | SIMATIC NET |
| Product Type | Industrial Ethernet / PROFIBUS Gateway |
| Supply Voltage | 24 VDC |
| Supply Voltage Tolerance | -1.333333333 |
| Typical Current Consumption | 0.2 A @ 24 VDC |
| Maximum Current Consumption | 0.3 A @ 24 VDC |
| Power Loss | 4.8 W |
| PROFINET IO Functionality | Yes |
| PROFINET IO Device | Yes |
| S7 Routing | Yes |
| Data Record Routing | Yes |
| Industrial Ethernet Transfer Rate | 10–100 Mbit/s |
| PROFIBUS Transfer Rate | 9.6 kbit/s–12 Mbit/s |
| Industrial Ethernet Interface | 1 Interface |
| Industrial Ethernet Connections | 2 × RJ45 |
| PROFIBUS Interface | 1 × 9-Pin Sub-D, RS-485 |
| Power Supply Connection | 4-Pole Terminal Block |
| C-PLUG | Yes |
| PROFIBUS DP Master | Yes |
| DP Master Service | DPV1 |
| Maximum Usable DP Slaves | 65 |
| DP Master Input Address Area | 2,048 Bytes Total |
| DP Master Output Address Area | 2,048 Bytes Total |
| Input Data per DP Slave | 244 Bytes |
| Output Data per DP Slave | 244 Bytes |
| Maximum S7 Communication Connections | 32 |
| Active Multi-Protocol Connections | 48 |
| Maximum Data Record Routing Connections | 32 |
| Ring Redundancy | Yes |
| Media Redundancy Protocol (MRP) | Yes |
| NTP | Yes |
| SICLOCK Support | Yes |
| Time Synchronization Forwarding | Yes |
| Protection Class | IP20 |
| Operating Temperature – Vertical Installation | 0 to 40°C |
| Operating Temperature – Horizontal Installation | 0 to 60°C |
| Storage Temperature | -40 to +70°C |
| Transport Temperature | -40 to +70°C |
| Maximum Relative Humidity | 95% @ 25°C, Non-Condensing |
| Mounting Type | 35 mm DIN Rail |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6GK1411-5AB10 is a SIMATIC NET IE/PB LINK PN IO Industrial Ethernet/PROFIBUS Gateway designed to integrate PROFINET and Industrial Ethernet systems with PROFIBUS DP networks. It provides routing and communication between Ethernet-based controllers and PROFIBUS field devices while supporting PROFINET IO, DP Master functionality, S7 routing, and data record routing. The 6GK1411-5AB10 is well suited for factory automation, distributed I/O, PROFIBUS modernization, PROFINET integration, process control, and maintenance of existing Siemens industrial communication networks.
