Product Name:Bus connector with axial cable outlet
Brand Name:Siemens
Model Number:6GK1500-0EA02
Country of Origin:Germany
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Siemens |
Model Number: |
6GK1500-0EA02 |
Country of Origin: |
Germany |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Details |
|---|---|
| Product Model | 6GK1500-0EA02 |
| Communication Type | PROFIBUS RS485 |
| Data Rate | 9.6 kbit/s – 12 Mbit/s |
| Electrical Connections | 2 x PROFIBUS cable terminals, 1 x Sub-D (9-pin) |
| Cable Outlet | 180° axial outlet |
| Termination | Integrated resistor with switch function |
| Housing Material | Metal (EMI shielded) |
| Protection Class | IP20 |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -25°C to +80°C |
| Humidity | Max 75% (non-condensing) |
| Dimension (W×H×D) | 15 × 57 × 39 mm |
| Weight | 100 g |
The 6GK1500-0EA02 is a robust industrial communication plug designed for reliable PROFIBUS network integration in automation systems. It supports high-speed data transmission and ensures stable signal connectivity for distributed field devices, including SIMATIC panels and industrial PCs.
The connector features an axial 180° cable outlet and an integrated terminating resistor with a selectable switch, enabling flexible bus termination and simplified commissioning. Its metal housing improves electromagnetic shielding, making it suitable for electrically noisy industrial environments.
With a transmission range of 9.6 kbit/s to 12 Mbit/s, the 6GK1500-0EA02 delivers consistent communication performance across PROFIBUS networks. It is widely used in factory automation, process control systems, and distributed control architectures requiring reliable RS485-based connectivity.
Q1: What is 6GK1500-0EA02 used for?
A1: It is used to connect PROFIBUS devices such as PLCs, HMIs, and industrial PCs to a PROFIBUS RS485 network.
Q2: What communication speed does it support?
A2: It supports data rates from 9.6 kbit/s up to 12 Mbit/s.
Q3: Does it include a terminating resistor?
A3: Yes, it has an integrated switchable terminating resistor for flexible bus configuration.
Q4: What type of connector does it use?
A4: It uses a 9-pin Sub-D interface for network device connection.
Q5: Is it suitable for harsh industrial environments?
A5: Yes, the metal housing provides strong EMI shielding for industrial use.
|
