Product Name: Optical Link Module
Brand Name: Siemens
Model Number: 6GK1503-2CB00
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The Siemens 6GK1503-2CB00 Optical Link Module is an industrial communication module designed to enable reliable optical data transmission in PROFIBUS-based automation networks. Manufactured in Germany, it provides secure and interference-free communication between distributed control system components, improving network stability in electrically noisy industrial environments.
With support for both PROFIBUS DP and PROFIBUS PA communication, the module ensures flexible and efficient integration across a wide range of industrial automation systems.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Siemens 6GK1503-2CB00 Optical Link Module |
| Manufacturer | Siemens |
| Product Type | Optical Link Module |
| Part Number | 6GK1503-2CB00 |
| Weight | 0.34 kg |
| Estimated shipping dimensions | 4x8.5x13.3cm |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Transfer rate / with PROFIBUS | 9.6 kbit/s ... 12 Mbit/s |
| Transfer rate / with PROFIBUS PA | 45.45 kbit/s |
| Type of voltage / of the supply voltage | DC |
| Supply voltage / at DC / Rated value | 24 V |
| Supply voltage / at DC | 18.8 ... 28.8 V |
| Product component / fusing at power supply input | Yes |
| Consumed current / at DC / at 24 V / maximum | 0.2 A |
The Siemens 6GK1503-2CB00 Optical Link Module is widely used in industrial automation systems requiring robust and interference-resistant communication.
High-Speed PROFIBUS Communication
Supports data transmission up to 12 Mbit/s for PROFIBUS DP, ensuring fast and efficient network performance.
Optical Signal Transmission Stability
Converts electrical signals into optical signals, eliminating electromagnetic interference for highly stable communication.
Dual Protocol Support
Compatible with both PROFIBUS DP and PROFIBUS PA, enabling flexible system integration.
Stable 24 V DC Operation
Operates within a wide DC voltage range (18.8–28.8 V), ensuring reliable power performance in industrial environments.
Low Power Consumption
Consumes a maximum of 0.2 A at 24 V DC, supporting energy-efficient system operation.
Enhanced Electrical Protection
Includes built-in fusing at the power input to improve safety and system reliability.
Industrial-Grade Robustness
Designed for continuous operation in harsh environments with strong resistance to electrical noise and interference.
