Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Model Number
|
6GK5101-1BC00-2AA3
|
|
Copper Ethernet ports
|
1 × RJ45, 10/100 Mbit/s
|
|
Optical Ethernet ports
|
1 × 100 Mbit/s single-mode
|
|
Optical connector
|
ST/BFOC
|
|
Total network connections
|
2
|
|
Transmitter optical output
|
-5 to 0 dBm
|
|
Maximum receiver input
|
0 dBm
|
|
Receiver sensitivity
|
-35 dBm
|
|
Minimum link attenuation
|
0 dB
|
|
Optical transmission range
|
0–26 km, fiber dependent
|
|
Rated supply voltage
|
24 V DC
|
|
Permissible supply range
|
18–32 V DC
|
|
Maximum current consumption
|
0.12 A
|
|
Power loss at 24 V DC
|
3 W
|
|
Input fuse
|
0.5 A / 60 V
|
|
Power connector
|
4-pole terminal block
|
|
Signaling connector
|
2-pole terminal block
|
|
Signaling contact voltage
|
24 V DC rated
|
|
Signaling contact current
|
0.1 A maximum
|
|
Operating temperature
|
-10 to +60 °C
|
|
Storage temperature
|
-40 to +80 °C
|
|
Transport temperature
|
-40 to +80 °C
|
|
Relative humidity at 25 °C
|
95% maximum, non-condensing
|
|
Enclosure protection
|
IP30
|
|
MTBF
|
134 years
|
|
Safety standards
|
UL 60950-1; CSA C22.2 No. 60950-1
|
|
Hazardous-location rating
|
Class I, Division 2, Groups A–D
|
|
EMC conformity
|
EN 61000-6-2:2001; EN 61000-6-4:2001
|
|
Mounting options
|
35 mm DIN rail, S7-300 rail or wall
|
|
Redundant supply connections
|
2 DC supply inputs
|
|
Conformity marks
|
CE, C-Tick, KC
|
|
Sales
Jim Pei
|
Email
|
Phone/Whatsapp
|
Siemens 6GK5101-1BC00-2AA3 is the SCALANCE X101-1LD unmanaged Industrial Ethernet media converter. It connects a copper RJ45 link to a single-mode fiber link. The optical interface operates at 100 Mbit/s. A redundant DC supply arrangement supports the industrial network installation. LED diagnostics and an error-signaling contact provide local status information.
The converter is intended for Ethernet links that require a transition between copper and optical cabling. Its set pushbutton supports the device signaling configuration. The optical connection uses BFOC connectors. DIN rail, S7 mounting rail and wall installation are supported. Select the fiber and verify the optical budget for the actual cable route.
|
