Siemens 6GK5202-2BB10-2BA3 SCALANCE X202-2IRT Switch

Siemens 6GK5202-2BB10-2BA3 SCALANCE X202-2IRT Switch

Product Name: SCALANCE X202-2IRT Managed Industrial Ethernet Switch

Brand Name: Siemens

Model Number: 6GK5202-2BB10-2BA3

Place of Origin: Germany

Warranty: 12 Months

Whatsapp: +86 18020776782

Email: [email protected]

Overview
Description
Contact info
Specifications
Commercial Term
FAQ
Other Products
Recommended Products

Protect an IRT cell network when copper and multimode fiber meet

A managed industrial Ethernet switch with two 10/100 Mbps RJ45 ports and two 100 Mbps multimode BFOC optical ports.

Verify first: Preserve the PROFINET device name, topology, redundancy settings and any optional C-PLUG before moving cables.

Description

Siemens specifies the X202-2IRT for PROFINET IO networks with integrated Redundancy Manager, network management, an error-signaling contact and redundant power input. Its optical ports are the multimode BFOC variant, not a generic interchangeable fiber interface.

When replacing an installed switch, map the two copper and two optical links, note the existing configuration and confirm the approved IRT topology. Restore settings under a maintenance plan and verify controller and link diagnostics before returning the cell to production.

Communication & Connectivity

Match the installed multimode fiber medium and BFOC connectors as well as the RJ45 port map. Confirm the PROFINET IO device name and IRT network configuration in the project.

Installation & Integration

Check both power feeds, the signaling contact and the use of an optional C-PLUG. Label every connection before disconnecting the existing switch and test the restored network path.

Contact info

CONTACT

Jim Pei

[email protected]

+86 180 2077 6782

Specifications

Product family

SCALANCE X-200IRT managed

Copper interfaces

2 × RJ45, 10/100 Mbps

Optical interfaces

2 × multimode BFOC, 100 Mbps

Network role

Managed PROFINET IO / IRT switch

Redundancy

Integrated Redundancy Manager

Diagnostics

Error-signaling contact with set button

Power

Redundant supply input

Configuration medium

C-PLUG optional

Commercial Term

Quotation

Current price and availability

Payment

T/T or agreed terms

Lead time

Confirmed with quotation

Shipping

DHL, FedEx, UPS or agreed freight

Warranty

12 months

FAQ

How can I confirm 6GK5202-2BB10-2BA3 matches the installed IRT switch?

Compare the full order number, two RJ45 and two multimode BFOC connections, firmware and saved configuration. Verify the project topology and power wiring before ordering.

What should be archived before replacing 6GK5202-2BB10-2BA3?

Export the approved switch configuration and record the PROFINET device name, IP settings, redundancy role and cable destinations. Identify whether a C-PLUG is fitted and preserve it under the site procedure.

Why might optical links stay down after 6GK5202-2BB10-2BA3 is installed?

Check that the fiber and BFOC connectors match the multimode ports, clean and seat both ends, confirm transmit/receive routing, then review port diagnostics and the partner device.

What should I inspect if an IRT controller loses devices after exchanging 6GK5202-2BB10-2BA3?

Compare the physical topology and device name with the engineering project, then check link status, synchronization and redundancy diagnostics. Restore only the validated configuration.

How should I interpret an error-signaling contact on 6GK5202-2BB10-2BA3?

Read the switch diagnostics and port LEDs, inspect both power inputs and the optical path, and correlate the alarm with the configured fault-signaling rules before replacing hardware.

What information should a buyer send for 6GK5202-2BB10-2BA3?

Provide the exact order number, installed switch label, fiber connector and medium, firmware constraints, C-PLUG use, required condition and destination.
