Product Name: SIMATIC NET CP 443-1 Advanced Communications Processor
Brand Name: Siemens
Model Number: 6GK7443-1GX30-0XE0
Place of Origin: Germany
Warranty: 12 Months
Whatsapp: +86 18020776782
Email: [email protected]
Fast response for industrial automation sourcing
| SalesJim Pei | Email[email protected] | Phone/Whatsapp+86 18020776782 |
| PARAMETER | OFFICIAL VALUE |
|---|---|
| Model Number | 6GK7443-1GX30-0XE0 |
| at the 1st interface | 10 ... 1000 Mbit/s |
| at the 2nd interface | 10 ... 100 Mbit/s |
| supply voltage / 1 / from backplane bus | 5V |
| power loss [W] | 9W |
| during transport | 40 ... +70 °C |
| protection class IP | IP20 |
| as user data per ISO connection / for open | 8 Kibyte |
| as user data per ISO on TCP connection / for open | 8 Kibyte |
| as user data per TCP connection / for open | 8 Kibyte |
| as user data per UDP connection / for open IE | 2 Kibyte |
| as flash memory file system | 30 Mibyte |
| product function / is supported / identification link | Yes; acc. to IEC 61406-1:2022 |
| type of encryption algorithms / with VPN connection | AES-256, AES-192, AES-128, 3DES-168, DES-56 |
| type of authentication procedure / with VPN connection | Preshared key (PSK), X.509v3 certificates |
| type of hashing algorithms / with VPN connection | MD5, SHA-1 |
| product type designation | CP 443-1 Advanced |
| at 5 V | 5% |
| from backplane bus / at DC / at 5 V / typical | 1.8 A |
| during operation | 0 ... 60 °C |
| during storage | 40 ... +70 °C |
| at 25 °C / without condensation / during operation / | 95 % |
| note | max. 4 as PN IO ctrl. |
| maximum | 128; when using several CPUs |
| data volume / as user data for email / maximum | 8 Kibyte |
| as RAM | 16 Mibyte |
| additionally buffered as RAM via central backup battery | 512 Kibyte |
| as user data for input variables / as PROFINET IO | 4 Kibyte |
| as user data for output variables / as PROFINET IO | 4 Kibyte |
| as user data for input variables per PN IO device / as | 1433 byte |
| as user data for output variables per PN IO device / as | 1433 byte |
| as user data for input variables per PN IO device / for | 240 byte |
| as user data for output variables per PN IO device / for | 240 byte |
| required | STEP 7 V5.5 SP3 or higher / STEP 7 Professional V12 (TIA Portal) or higher |
| to website: Selection guide for cables and connectors | https://support.industry.siemens.com/cs/ww/en/view/109766358 |
|
01
6GK7443-1GX30-0XE0 is suitable for S7-400 Ethernet communication, PROFINET IO control, plant networking, and controller integration. |
02
It can also support TCP, UDP, ISO transport, S7 routing, diagnostics, web-server, FTP, and email communication. |
|
