Product Name: 3300 XL 8 mm Reverse Mount Probe
Brand Name: Bently Nevada
Model Number: 330105-00-05-10-02-00
Place of Origin: United States
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Tag
| Bently Nevada 3300 XL 8 mm Reverse Mount Probe | Industrial Condition Monitoring |
| 330105-00-05-10-02-00 | Compact Mount Proximity Probe |
| Reverse Mount Proximity Probe | 3300 XL Series Probe |
| Eddy Current Sensor | PPS Tip Sensor |
| Vibration Monitoring Probe | Stainless Steel Probe Housing |
| Shaft Position Sensor | ClickLoc Connector Probe |
| Rotating Machinery Monitoring | API 670 Compliant Probe |
| Fluid-Film Bearing Monitoring | Machinery Protection System |
| Dynamic Vibration Measurement | Predictive Maintenance Sensor |
| Static Position Measurement | Industrial Automation Sensor |
The Bently Nevada 330105-00-05-10-02-00 is a 3300 XL 8 mm Reverse Mount Probe designed for precise shaft vibration and position monitoring in rotating industrial machinery. As part of the 3300 XL Proximity Transducer System, it works together with extension cables and Proximitor sensors to provide accurate static and dynamic measurement signals.
Its reverse mount configuration allows installation in compact or restricted mounting spaces while maintaining high measurement accuracy and stability. The probe utilizes advanced eddy current sensing technology to deliver reliable vibration and position monitoring for fluid-film bearing machines and critical industrial equipment.
Constructed with a PPS (Polyphenylene Sulfide) probe tip and AISI 303/304 stainless steel housing, the 330105-00-05-10-02-00 offers strong mechanical durability and corrosion resistance. The system complies with API 670 standards and supports backward compatibility with 3300 series 5 mm and 8 mm non-XL components, simplifying upgrades and maintenance.
|
Sales |
|
|
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Winnie |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | Bently Nevada 330105-00-05-10-02-00 3300 XL 8 mm Reverse Mount Probe |
| Manufacturer | Bently Nevada |
| Product Type | 3300 XL 8 mm Reverse Mount Probe |
| Part Number | 330105-00-05-10-02-00 |
| Dimensions | 1.8x1.6x112cm |
| Weight | 0.1kg |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Option Descriptions | 1.0 meter (3.3 feet) |
| Connector and Cable-Type Option | Miniature ClickLoc coaxial connector |
| Agency Approval Option | Not required |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Case Material | AISI 303 or 304 stainless steel (SST) |
1. What connector type does 330105-00-05-10-02-00 use?
The 330105-00-05-10-02-00 features a miniature ClickLoc coaxial connector for secure and convenient installation.
2. What is the cable length of 330105-00-05-10-02-00?
The 330105-00-05-10-02-00 includes a standard cable length of 1.0 meter (3.3 feet).
3. Does 330105-00-05-10-02-00 comply with API 670 standards?
Yes, the 330105-00-05-10-02-00 meets API 670 requirements for measurement accuracy, linearity, and temperature stability.
4. Can 330105-00-05-10-02-00 support Keyphasor applications?
Yes, the 330105-00-05-10-02-00 supports Keyphasor reference and speed monitoring applications.
5. Is 330105-00-05-10-02-00 backward compatible with older systems?
Yes, the 330105-00-05-10-02-00 is backward compatible with 3300 series 5 mm and 8 mm non-XL components.
6. Why is 330105-00-05-10-02-00 important for industrial monitoring?
The 330105-00-05-10-02-00 provides reliable vibration and position measurements, helping reduce downtime, improve equipment safety, and support predictive maintenance strategies.
