Product Name: RFID Connection Block
Brand Name: Siemens
Model Number: 6GT2002-1HD01
Place of Origin: Germany
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Sales: |
Email: |
Whatsapp: |
Jim Pei |
| Product Name | Siemens 6GT2002-1HD01 RFID Connection Block |
| Manufacturer | Siemens |
| Product Type | RFID Connection Block |
| Part Number | 6GT2002-1HD01 |
| Place of shipment | Xiamen, China |
| Country of origin | Germany |
| Compatible Module | RF170C Communication Module |
| Supported Readers | Up to 2 Readers |
| Communication Interfaces | RS-422 / RS-232 |
| Reader Connection | M12, 8-pin Connector |
| Point-to-Point Interface | RS-422 / RS-232 |
| Housing Material | Die-cast Zinc |
| Color | Silver |
| Rated Supply Voltage | 24 V DC |
| Operating Voltage Range | 20–30 V DC |
| Protection Rating | IP67 |
| Operating Temperature | -25°C to +55°C |
| Storage Temperature | -40°C to +70°C |
| Transport Temperature | -40°C to +70°C |
| Shock Resistance | According to IEC 61131-2 |
| Shock Acceleration | 300 m/s² |
| Vibration Resistance | 100 m/s² |
| Mounting Method | 4 Screws Included |
| Status Indicators | 4 LEDs per Reader Connection, 1 Device Status LED |
| Maximum Tightening Torque | 1.5 N·m |
| Certifications | CE, FCC, cULus |
| MTBF | 1100 Years |
| Reference Code | IEC 81346-2:2019 – KEC |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
The Siemens 6GT2002-1HD01 RFID Connection Block is an industrial RFID connection block designed for use with the RF170C communication module. It supports up to two RFID readers through RS-422/RS-232 communication and features rugged IP67 protection for reliable operation in demanding environments. With a durable die-cast zinc housing, integrated LED status indicators, and simple M12 connectivity, it provides dependable RFID communication for industrial identification and tracking applications.
Compared with similar RFID connection blocks, the Siemens 6GT2002-1HD01 offers robust environmental protection, flexible reader connectivity, and reliable industrial communication.
Q1: What is the 6GT2002-1HD01 used for?
A1: 6GT2002-1HD01 is used to connect RFID readers to the RF170C communication module in industrial RFID systems.
Q2: How many RFID readers does the 6GT2002-1HD01 support?
A2: 6GT2002-1HD01 supports connections for up to two RFID readers.
Q3: Which communication interfaces are supported by the 6GT2002-1HD01?
A3: 6GT2002-1HD01 supports RS-422 and RS-232 communication interfaces.
Q4: Which communication module is compatible with the 6GT2002-1HD01?
A4: 6GT2002-1HD01 is designed for use with the RF170C communication module.
Q5: What connector type does the 6GT2002-1HD01 use?
A5: 6GT2002-1HD01 uses M12 8-pin connectors for RFID reader connections.
Q6: What is the operating voltage of the 6GT2002-1HD01?
A6: 6GT2002-1HD01 operates with a 24 V DC supply and supports an operating range of 20–30 V DC.
