Siemens 6SL3040-1MA00-0AA0 SINAMICS S120 CU320-2 DP Control Unit

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Specifications

Model Number	6SL3040-1MA00-0AA0
Rated electronics supply	24 V DC
Permissible electronics supply	20.4–28.8 V DC
Maximum electronics current	1 A, excluding digital outputs, option slot and DRIVE-CLiQ supply
Maximum power loss	24 W
Isolated digital inputs	12 inputs
Digital input voltage	-3 to +30 V
Digital input low level	-3 to +5 V
Digital input high level	15–30 V
Typical input current at 24 V	3.5 mA per digital input
Typical digital-input rising delay	50 µs
Bidirectional digital I/O	8 non-isolated channels
Fast I/O input rising delay	5 µs
Fast I/O input falling delay	50 µs
Digital output voltage	24 V DC at digital output
Maximum current per digital output	500 mA
Output rising delay	150 µs typical / 400 µs maximum
Output falling delay	75 µs typical / 100 µs maximum
DRIVE-CLiQ connections	4 connections
RS-232 connections	1 serial connection
Service Ethernet connections	1 Ethernet interface
Measuring sockets	3 measuring sockets
CompactFlash slots	1 card slot
Option-module slots	1 expansion slot
PE connection	1 × M5 screw
Installation altitude	2000 m
Operating temperature	0 to +55 °C
Storage temperature	-25 to +55 °C
Transport temperature	-40 to +70 °C
Maximum transport relative humidity	95% at 40 °C
Maximum supply conductor cross-section	2.5 mm²
Maximum digital I/O conductor cross-section	1.5 mm²
Maximum fuse protection	20 A
Automation network	PROFIBUS DP
PROFIBUS connections	1 PROFIBUS interface

Contact info

Sales

Jim Pei

Email

[email protected]

Phone/Whatsapp

+86 18020776782

Description

01

Siemens 6SL3040-1MA00-0AA0 is the SINAMICS S120 CU320-2 DP Control Unit. Its automation interface uses the PROFIBUS DP configuration. The unit provides DRIVE-CLiQ connections for supported drive components. Isolated digital inputs and bidirectional digital I/O support local signal connections. The electronics operate from a DC supply.

02

The DP control unit belongs to the corresponding SINAMICS drive-system configuration. Its service Ethernet connection must be distinguished from a PROFINET automation interface. A suitable CompactFlash card is required for operation. The configured drive topology and firmware must match the installed components. Verify the full control-unit designation when planning a replacement.

Diagnostics

01

PROFIBUS connection

Check the DP network configuration and the selected control-unit target during commissioning.

02

Service access

The service Ethernet interface does not change this unit into the PN automation configuration.

03

Configured drive topology

Compare the DRIVE-CLiQ arrangement and CompactFlash firmware with the intended drive project.

FAQ

01

Does the Ethernet socket make 6SL3040-1MA00-0AA0 a PROFINET unit?

No. This order identifies the CU320-2 DP; its service Ethernet connection is separate from the automation fieldbus configuration.

02

Which CompactFlash firmware starts operation of 6SL3040-1MA00-0AA0?

The Siemens catalog specifies firmware V4.3 or later for the CU320-2 DP configuration.

03

Can 6SL3040-1MA00-0AA0 directly replace a PN-configured unit?

Do not assume a direct replacement. The automation interface and engineering configuration differ and require review.

04

What information helps identify the correct 6SL3040-1MA00-0AA0 spare?

Provide the complete label, CompactFlash firmware and drive project details so the intended configuration can be checked.

05

Will you confirm the actual 6SL3040-1MA00-0AA0 before sending it?

Yes. Label photos, condition and supplied items can be confirmed. Each item is tested before delivery with the agreed 12-month warranty.

06

Is prompt dispatch available for 6SL3040-1MA00-0AA0?

Yes. Available stock is dispatched immediately after payment is received; we provide tracking details.
