SIEMENS 6SL3120-1TE28-5AA3 SINAMICS Motor Module In stock

SIEMENS 6SL3120-1TE28-5AA3 SINAMICS Motor Module In stock

Product Name:SINAMICS Motor Module

Brand Name:SIEMENS

Model Number:6SL3120-1TE28-5AA3

Country of Origin:Germany

Warranty:12 Months

Whatsapp：+86 18159889985

Email：[email protected]

Appurtenance:

siemens 6sl3120 1te28 5aa3 sinamics motor module in stock-1

Overview
Contact for quotation
Specifications
Description
Applications
Technical Data Summary
Environmental Strength
FAQ
Spares
Recommended Products

Overview

Brand Name:	SIEMENS
Model Number:	6SL3120-1TE28-5AA3
Country of Origin:	Germany
Packaging Details:	Original new Factory Sealed
Delivery Time:	in stock
Payment Terms:	T/T

Contact for quotation

Sales Manager:	Stella
Send an email:	[email protected]
Contact in Whatsapp:	+86 18159889985

Specifications

Parameter	Specification
Product Model	6SL3120-1TE28-5AA3
Manufacturer	Siemens
Product Type	SINAMICS Motor Module
DC Link Voltage	510–720 VDC
Electronics Supply	24 VDC (-15% / +20%)
Rated Output Current	85 A
Base Load Current	68 A
Maximum Output Current	141 A
Rated Power	46 kW (IN), 37 kW (IH)
Pulse Frequency	4 kHz
Servo Output Frequency	0–650 Hz
Vector Output Frequency	0–300 Hz
V/f Output Frequency	0–600 Hz
Cooling Method	Internal air cooling with integrated fan
Protection Rating	IP20 / UL Open Type
Construction	Booksize
Operating Temperature	0°C to +40°C
Dimensions (W × H × D)	200 × 380 × 270 mm
Weight	Approx. 15 kg
Certifications	CE, cULus, IEC 61508 SIL2, EN ISO 13849-1 PL d Category 3

Description

6SL3120-1TE28-5AA3 is a high-performance Siemens SINAMICS Motor Module developed for precision motion control and demanding industrial drive systems. Designed with a DC link voltage range of 510–720 VDC, the module delivers stable power conversion, high current capability, and reliable motor performance for continuous production environments. Its compact Booksize construction allows efficient cabinet installation while supporting high power density.

As part of the Siemens SINAMICS drive platform, 6SL3120-1TE28-5AA3 integrates seamlessly with compatible control units and shared DC bus architectures. Similar products such as 6SL3120-1TE28-5AA4 and other SINAMICS Motor Modules provide flexible scalability for multi-axis automation systems, helping simplify engineering, commissioning, and long-term maintenance.

Featuring internal air cooling, Safety Integrated technology, and support for servo, vector, and V/f control modes, 6SL3120-1TE28-5AA3 is well suited for CNC machines, robotics, packaging systems, conveyor lines, and other high-dynamic industrial applications requiring dependable speed regulation and excellent operational efficiency.

Applications

Power plants: Provides accurate motor drive control for auxiliary pumps, cooling fans, turbine support equipment, and automated power generation systems.
Substations: Supports ventilation equipment, auxiliary motor drives, and electrical infrastructure automation requiring dependable variable-speed control.
Chemical plants: Controls mixers, compressors, dosing pumps, and processing machinery with high operational stability and precise motion performance.
Steel mills: Operates rolling equipment, conveyor systems, hydraulic drives, and heavy-duty production machinery under harsh industrial conditions.
Machinery manufacturing plants: Ideal for CNC machining centers, robotic cells, automated assembly lines, packaging systems, and precision motion control applications.
Automotive production: Delivers synchronized multi-axis motion for welding, painting, material handling, and assembly equipment.
Logistics systems: Drives conveyors, sorting equipment, and warehouse automation with reliable high-speed motor control.

Technical Data Summary

High DC Bus Performance: Operates from 510–720 VDC to provide stable energy conversion for demanding industrial drives.
Power Capability: Delivers 85 A rated current with overload capability up to 141 A for dynamic applications.
Multiple Control Modes: Supports servo, vector, and V/f motor control for flexible machine integration.
Efficient Cooling: Integrated air cooling maintains reliable thermal performance during continuous production.
Compact Installation: Booksize mechanical design optimizes cabinet space while maintaining service accessibility.
Low Power Loss: Typical converter loss of only 0.77 kW contributes to improved overall system efficiency.
Wide Cable Compatibility: Supports shielded motor cables up to 100 m and unshielded cables up to 150 m.
Industrial Reliability: Designed for high-duty automation systems requiring continuous operation.

Environmental Strength

Wide Operating Temperature: Stable operation from 0°C to +40°C for industrial production environments.
Altitude Capability: Full performance maintained up to 1,000 meters without output derating.
Internal Cooling System: High-efficiency integrated fan improves thermal management and long-term reliability.
Industrial Protection: IP20 enclosure is suitable for installation inside protected electrical cabinets.
Safety Integrated: Certified to SIL2 and PL d Category 3, supporting machine functional safety requirements.
International Compliance: Meets CE and cULus certification standards for global industrial applications.
Quiet Operation: Typical sound pressure level of only 60 dB helps reduce cabinet noise.
Long Service Life: Engineered for demanding automation environments requiring dependable continuous-duty operation.

FAQ

Q1: What is 6SL3120-1TE28-5AA3 used for?
A1: It is a Siemens SINAMICS Motor Module designed for high-performance servo and variable-speed motor control in industrial automation systems.

Q2: What DC voltage does 6SL3120-1TE28-5AA3 require?
A2: The module operates with a DC link voltage ranging from 510 VDC to 720 VDC.

Q3: What is the rated output current of this Motor Module?
A3: The rated output current is 85 A, with overload capability reaching 141 A.

Q4: Does 6SL3120-1TE28-5AA3 support functional safety?
A4: Yes. It features Siemens Safety Integrated technology certified to SIL2 and PL d Category 3.

Q5: Which industries commonly use 6SL3120-1TE28-5AA3?
A5: It is widely applied in CNC machinery, robotics, packaging equipment, automotive manufacturing, material handling systems, steel production, and process automation.
