Product Name:logic module
Brand Name: SIEMENS
Model Number:6ED1052-1FB00-0BA6
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
6ED1052-1FB00-0BA6 |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Details |
|
Manufacturer |
Siemens |
|
Product Type |
LOGO! 230RC Logic Module |
|
Order Number |
6ED1052-1FB00-0BA6 |
|
Supply Voltage |
115 … 240 V AC/DC |
|
Permissible Range (AC) |
85 … 265 V AC |
|
Permissible Range (DC) |
100 … 253 V DC |
|
Mains Frequency |
47 … 63 Hz |
|
Voltage Failure Bridging (115 V) |
typ. 10 ms |
|
Voltage Failure Bridging (240 V) |
typ. 20 ms |
|
Real-Time Clock Backup |
typ. 80 h |
|
Time Switching Clocks |
8 |
|
Digital Inputs |
8 |
|
Digital Outputs |
4 relay |
|
Output Switching (resistive) |
max. 10 A |
|
Output Switching (inductive) |
max. 3 A |
|
Memory Capacity |
200 function blocks |
|
Short-Circuit Protection |
external fuse required |
|
Display |
integrated LCD with background lighting |
|
Mounting |
on 35 mm DIN rail, 4 spacing units wide |
|
Protection Rating |
IP20 |
|
Dimensions (W × H × D) |
72 × 90 × 55 mm |
|
Weight |
approx. 0.26 kg |
|
Operating Temperature |
0 … 55 °C |
|
Approvals |
CE, CSA, UL, FM, Marine, VDE 0631, IEC 61131 |
|
Radio Interference |
EN 55011 Limit Class B |
|
Country of Origin |
Germany / China (depends on production batch) |
The Siemens 6ED1052-1FB00-0BA6 is a compact LOGO! 230RC logic module designed for small‑scale automation tasks. Integrating a controller, operator display, and power supply into one unit, the 6ED1052-1FB00-0BA6 replaces multiple traditional timers, relays, and counters. It operates on 115 … 240 V AC/DC, provides eight digital inputs and four relay outputs, and stores up to 200 function blocks. The Siemens 6ED1052-1FB00-0BA6 simplifies wiring while offering flexible expandability for building and industrial applications.
Building automation: stairway lighting, shutters, sun blinds, and corridor lighting
Gate and door control systems (factory doors, automatic doors)
HVAC: ventilation systems, air‑conditioning, pump controls
Machine control: conveyors, mixing equipment, bending machines
Greenhouse automation: irrigation and climate control
Compressed air drying systems and silo‑filling equipment
Direct 115/230 V AC/DC supply (no external power supply needed)
Eight digital inputs and four relay outputs (10 A resistive)
200 block memory capacity for complex logic
Integrated LCD display with background lighting for local operation
Built‑in real‑time clock with 80 hour backup
Expandable with digital, analog, and communication modules
Compact 72 mm width fits tight control cabinets
Programmable logic control via circuit diagram programming
Time‑based switching with up to 8 weekly timers
On‑delay, off‑delay, and on/off‑delay timing functions
Up/down counters and hour counter with retentive memory
Analog value processing (with AM2 expansion modules)
Latching relay, pulse relay, and shift register logic
Message text display on integrated screen
Q1: What is the Siemens 6ED1052-1FB00-0BA6 used for?
A1: It is a compact logic module for small automation tasks like lighting, gate control, HVAC and pump systems.
Q2: Does the 6ED1052-1FB00-0BA6 have a built‑in real‑time clock?
A2: Yes, it has an integrated RTC with 8 time switching clocks and an 80‑hour power reserve.
Q3: What is the maximum number of function blocks the Siemens 6ED1052-1FB00-0BA6 supports?
A3: It supports up to 200 function blocks, allowing complex logic sequences for demanding applications.
Q4: Can the 6ED1052-1FB00-0BA6 be expanded with additional modules?
A4: Yes, it is expandable with digital (DM8, DM16), analog (AM2), and communication (AS‑Interface) modules.
Q5: What software is required to program the Siemens 6ED1052-1FB00-0BA6?
A5: Use LOGO! Soft Comfort V8 or higher to create, simulate, and transfer programs via PC cable or Ethernet.
