Product Name:Programmable Control Module
Brand Name: SIEMENS
Model Number:6ED1052-2FB00-0BA4
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
6ED1052-2FB00-0BA4 |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Details |
|
Model |
6ED1052-2FB00-0BA4 |
|
Manufacturer |
Siemens |
|
Product Type |
LOGO! 230RCo Logic Module |
|
Voltage Class |
115 … 240 V AC/DC |
|
Permissible Range (AC) |
85 … 265 V AC |
|
Permissible Range (DC) |
100 … 253 V DC |
|
Mains Frequency |
47 … 63 Hz |
|
Power Consumption (115 V AC) |
10 … 30 mA (typ.) |
|
Power Consumption (240 V AC) |
10 … 20 mA (typ.) |
|
Voltage Failure Bridging |
typ. 10 ms (115 V), typ. 20 ms (240 V) |
|
Power Loss (115 V AC) |
1.1 … 3.5 W |
|
Power Loss (240 V AC) |
2.3 … 4.6 W |
|
Real-Time Clock Backup |
typ. 80 h at 25 °C |
|
Digital Inputs |
8 (no isolation, two groups of 4) |
|
Input Signal ”0” (AC) |
< 40 V AC |
|
Input Signal ”1” (AC) |
> 79 V AC |
|
Input Signal ”0” (DC) |
< 30 V DC |
|
Input Signal ”1” (DC) |
> 79 V DC |
|
Input Current @ Signal ”1” |
> 0.08 mA |
|
Delay 0 → 1 (120 V AC) |
typ. 50 ms |
|
Delay 0 → 1 (240 V AC) |
typ. 30 ms |
|
Delay 0 → 1 (120 V DC) |
typ. 25 ms |
|
Delay 0 → 1 (240 V DC) |
typ. 15 ms |
|
Digital Outputs |
4, relay type |
|
Max. Continuous Current (Ith) |
5 A per relay (10 A total per common) |
|
Switching Capacity (resistive) |
10 A max. |
|
Switching Capacity (inductive) |
3 A max. |
|
Incandescent Lamp Load |
1000 W (230/240 V AC), 500 W (115/120 V AC) |
|
Fluorescent Tubes (ballast) |
10 × 58 W (230/240 V AC) |
|
Short-Circuit Protection |
not integrated, external fuse needed |
|
Program Memory |
130 blocks (0BA4 version) |
|
Display |
none (”Pure” version) |
|
Mounting |
35 mm DIN rail, 4 spacing units wide |
|
Protection Rating |
IP20 |
|
Dimensions (W × H × D) |
72 × 90 × 55 mm |
|
Weight |
approx. 190 g |
|
Operating Temperature |
0 … 55 °C |
|
Certifications |
CE, cULus, FM, CSA, Marine, VDE 0631, IEC 61131 |
The Siemens 6ED1052-2FB00-0BA4 is a compact LOGO! 230RCo logic module designed for small‑scale automation without a display. Operating on 115 … 240 V AC/DC, the Siemens 6ED1052-2FB00-0BA4 provides eight digital inputs and four relay outputs for direct load control. Its real‑time clock ensures precise timing, while the modular design allows flexible expansion with up to 24 digital and 8 analog I/O. The 6ED1052-2FB00-0BA4 delivers reliable automation for building and industrial applications at a cost‑effective price.
Lighting and shutter controls in buildings
Gate, door and garage automation
Heating, ventilation and air‑conditioning (HVAC)
Pump and irrigation controls
Small machine and conveyor controls
Signal processing and monitoring tasks
Compact, space‑saving design (72 mm width)
Direct 115/230 V AC/DC operation (no external power supply needed)
Eight digital inputs and four relay outputs
Built‑in real‑time clock with 80 h backup
Up to 130 function blocks for complex programs
Expandable with digital, analog and communication modules
IP20 protection for control cabinet installation
Programmable logic control via circuit‑diagram programming
Time‑based switching (weekly/yearly timer, on‑/off‑delay)
Counter and threshold trigger functions
Analog value processing (with AM2 expansion)
Latching relay and pulse relay logic
Remote monitoring and diagnostics via LOGO! Soft Comfort
Q1: What is the Siemens 6ED1052-2FB00-0BA4 used for?
A1: It is a logic module for small automation tasks, e.g. lighting, gate control, HVAC and pump systems.
Q2: Does the 6ED1052-2FB00-0BA4 have a display?
A2: No, it is the ”Pure” version without display. Programming is done via PC software or a program module.
Q3: What is the power supply range of the Siemens 6ED1052-2FB00-0BA4?
A3: It accepts 85 … 265 V AC or 100 … 253 V DC, making it suitable for direct mains connection.
Q4: Can the 6ED1052-2FB00-0BA4 be expanded?
A4: Yes, you can connect up to 24 digital inputs and 8 analog inputs using DM8, DM16 and AM2 expansion modules.
Q5: What memory capacity does the 6ED1052-2FB00-0BA4 provide?
A5: It supports up to 130 function blocks, enough for many small to medium control applications.
