Product Name:Logic Module
Brand Name: SIEMENS
Model Number:6ED1052-2CC01-0BA8
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
6ED1052-2CC01-0BA8 |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Details |
|
Manufacturer |
Siemens |
|
Product Type |
LOGO! 24CEO Logic Module |
|
Order Number |
6ED1052-2CC01-0BA8 |
|
Product Family |
SIMATIC LOGO! 8 |
|
Product Lifecycle Status |
Discontinued (since 2019-10-01) |
|
Successor |
6ED1052-2CC08-0BA2 |
|
Supply Voltage (Rated) |
24 V DC |
|
Permissible Range (DC) |
20.4 … 28.8 V DC |
|
Digital Inputs |
8 |
|
Analog Inputs (configurable) |
4 (0 … 10 V) |
|
Digital Outputs |
4, transistor, 0.3 A per output |
|
Short-Circuit Protection |
Yes, electrical (1 A) |
|
Memory |
400 function blocks |
|
Real-Time Clock Power Reserve |
typ. 480 h |
|
Time Switching Clocks |
max. 400 (function-specific) |
|
Ethernet Interface |
1 × RJ45 10/100 Mb/s |
|
Web Server |
Integrated |
|
Data Logging |
Standard, via microSD card |
|
MicroSD Card Slot |
1 × standard microSD |
|
Display |
None ("CEO" version) |
|
Mounting |
on 35 mm DIN rail, 4 spacing units wide |
|
Radio Interference Suppression |
EN 55011 Limit Class B |
|
Protection Rating |
IP20 |
|
Operating Temperature |
0 … 55 °C (no condensation) |
|
Storage / Transport Temperature |
–40 … +70 °C |
|
Dimensions (W × H × D) |
71.5 × 90 × 58 mm |
The Siemens 6ED1052-2CC01-0BA8 is a display‑free LOGO! 24CEO logic module from the advanced LOGO! 8 generation. Designed for 24 V DC systems, the Siemens 6ED1052-2CC01-0BA8 provides eight digital inputs (four of which can be used as 0–10 V analog inputs) and four transistor outputs with integrated short‑circuit protection. With a generous 400‑block memory and an integrated Ethernet interface, the 6ED1052-2CC01-0BA8 enables fast programming and seamless networking. The built‑in web server and microSD data logging make the Siemens 6ED1052-2CC01-0BA8 a compact yet powerful automation solution for small to mid‑sized applications.
Building automation: lighting, blinds, HVAC
Gate and door control systems
Pump control (e.g. service water, irrigation)
Conveyor and sorting systems
Small machine control
Remote monitoring via integrated web server
400 function blocks for complex logic sequences
8 digital inputs, 4 of which are configurable as 0–10 V analog inputs
4 transistor outputs with built‑in short‑circuit protection (1 A)
Integrated Ethernet interface (RJ45, 10/100 Mb/s)
Built‑in web server for remote monitoring and control
Data logging to standard microSD card
480‑hour real‑time clock power reserve
Expandable with digital, analog and communication modules
Timer functions: on‑delay, off‑delay, on/off‑delay, weekly/yearly timer
Counter functions: up/down counter, hours counter, threshold trigger
Analog functions: comparator, threshold trigger, amplifier, differential trigger
Basic logic: AND, OR, XOR, NAND, NOT
Special functions: latching relay, pulse relay, shift register, message texts
Web server based remote monitoring and control
Q1: What is the Siemens 6ED1052-2CC01-0BA8 used for?
A1: It is a compact logic module for small automation tasks such as lighting control, pump systems, gate automation, and machine control.
Q2: Can the Siemens 6ED1052-2CC01-0BA8 be expanded with additional I/O?
A2: Yes, it supports up to 24 digital inputs, 20 digital outputs, 8 analog inputs and 8 analog outputs using expansion modules.
Q3: Does the 6ED1052-2CC01-0BA8 have a built‑in real‑time clock?
A3: Yes, it includes an RTC with up to 400 time switching clocks and a 480‑hour power reserve.
Q4: How can I program the Siemens 6ED1052-2CC01-0BA8?
A4: Use LOGO! Soft Comfort V8 or higher to create, simulate and transfer programs via the Ethernet interface or PC cable.
Q5: What is the status of the 6ED1052-2CC01-0BA8?
A5: This model is discontinued. Its successor is the 6ED1052-2CC08-0BA2 with additional cloud and MQTT features.
