Product Name:Logic Module
Brand Name: SIEMENS
Model Number:6ED1052-2HB08-0BA0
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
6ED1052-2HB08-0BA0 |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Product Type |
LOGO! 24RCEO (AC) Logic Module |
|
Article Number |
|
|
Manufacturer |
Siemens |
|
Mounting |
35 mm DIN rail, 4 spacing units wide |
|
Supply Voltage (DC) |
24 V DC (Permissible range: 20.4 ... 28.8 V DC) |
|
Supply Voltage (AC) |
24 V AC (Permissible range: 20.4 ... 26.4 V AC) |
|
Line Frequency |
47 ... 63 Hz |
|
Digital Inputs |
8 DI |
|
Digital Outputs |
4 DO (Relay) |
|
Output Current (per relay) |
max. 10 A (resistive load) |
|
Output Switching Voltage |
max. 250 V AC / 30 V DC |
|
Short-circuit Protection |
None; requires external fuse |
|
Memory Capacity |
400 blocks |
|
Real Time Clock Power Reserve |
480 h |
|
Ethernet Interface |
1 × RJ45 (10/100 Mb/s) |
|
Web Server |
Integrated |
|
Data Logging |
Standard (via microSD card) |
|
microSD Card Slot |
1 × standard microSD |
|
Display |
Without display (RCEO variant) |
|
Protection Rating |
IP20 |
|
Ambient Temp (Operating) |
-20 °C ... +55 °C |
|
Ambient Temp (Storage) |
-40 °C ... +70 °C |
|
Dimensions (W × H × D) |
71.5 × 90 × 58 mm |
|
Weight |
approx. 0.25 kg |
|
Approvals |
|
|
RoHS Compliant |
|
|
Country of Origin |
CN |
The Siemens 6ED1052-2HB08-0BA0 is a display-free logic module from the LOGO! 8 series. Designed for 24 V AC/DC systems, the 6ED1052-2HB08-0BA0 features 8 digital inputs and 4 relay outputs with a robust 10A switching capacity. Its 400-block memory enables complex program execution, while the integrated Ethernet interface and web server facilitate remote monitoring and control via user-defined web pages. The Siemens 6ED1052-2HB08-0BA0 is modularly expandable and offers data logging to a standard microSD card for comprehensive system management.
Building Automation: Lighting control, shutter/sun blind management, and HVAC systems.
Gate & Door Control: Automatic door systems, factory gates, and garage door openers.
Machine Control: Small machine automation, conveyor belt systems, and packaging equipment.
Pump & Irrigation: Service water pumps, rainwater harvesting systems, and agricultural irrigation.
General Automation: Replaces traditional relay and timer-based control panels in industrial and residential settings.
400-Block Memory: Supports more complex logic sequences and larger programs.
Integrated Ethernet: Built-in RJ45 port for networking and communication.
Integrated Web Server: Access and control the module via user-defined web pages from any browser.
Data Logging: Standard feature to log system performance data to an inserted microSD card.
Modular Expandability: Can be expanded with digital, analog, and communication modules (DM, AM, CM).
High Power Output: Directly switch large loads with relay outputs rated up to 10A.
Display-Free (RCEO): Cost-optimized version ideal for applications where local operator interface is not required.
Timer Functions: On-delay, Off-delay, On/Off-delay, Weekly/Yearly timer, Pulse generator.
Counter Functions: Up/down counter, hours counter, and threshold trigger.
Analog Value Processing: Expandable to include analog I/O for sensor and actuator control.
Basic & Special Functions: AND, OR, XOR, latching relay, pulse relay, shift register, softkey, and message text display.
Ethernet Communication: Remote monitoring, control, and data logging via web interface.
Real-Time Clock: Precise time-based switching with 480h power backup.
Q1: What is the Siemens 6ED1052-2HB08-0BA0 power supply requirement?
A1: It operates on either 24 V DC (20.4-28.8V) or 24 V AC (20.4-26.4V, 47-63Hz).
Q2: How much memory does the 6ED1052-2HB08-0BA0 have?
A2: It has 400 blocks of program memory for creating complex automation logic.
Q3: Can the Siemens 6ED1052-2HB08-0BA0 be expanded?
A3: Yes, it is modularly expandable with additional digital, analog, and communication modules (DM, AM, CM).
Q4: Does the 6ED1052-2HB08-0BA0 have an Ethernet port?
A4: Yes, it features an integrated Ethernet port (RJ45) with a web server for remote monitoring and control.
Q5: What software is needed to program the Siemens 6ED1052-2HB08-0BA0?
A5: Siemens LOGO! Soft Comfort (version V8 or higher) is required for programming and configuring the module.
