Home > Products > SIEMENS > Siemens Moore
Product Name:APACS Interconnect I/O Cable
Brand Name: SIEMENS
Model Number:16137-114
Country of Origin:GERMANY
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
SIEMENS |
Model Number: |
16137-114 |
Country of Origin: |
GERMANY |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
|
Parameter |
Specification |
|
Manufacturer |
Siemens Moore Process Automation, Inc. |
|
Model Number |
16137-114 |
|
Product Type |
|
|
Cable Length |
|
|
Connector Type |
Molded connector on module end; unterminated (stripped wires) on termination assembly end |
|
Voltage Rating |
|
|
Compatible Systems |
APACS+, QUADLOG, APACS MBX |
|
Function |
Connects I/O modules in rack to marshalled termination assembly for field wiring |
|
Weight |
Approx. 1.32 kg |
The SIEMENS 16137-114 is an Interconnect I/O Cable Assembly specifically engineered for the APACS+ and QUADLOG systems. This 16137-114 cable links I/O modules inside a Remote I/O Rack to external marshalled termination assemblies for field device wiring. The 16137-114 facilitates signal transmission and power delivery while maintaining electrical isolation. Designed for industrial environments, this 10-foot (3m) cable supports hot-swappable modules, enabling system maintenance without full power-downs . It is a core component for reliable system wiring and I/O expansion.
DCS Wiring: Connecting APACS+ I/O modules to field termination assemblies in distributed control systems.
System Refurbishment: Replacing aging or damaged cabling in legacy Siemens Moore automation racks.
Remote I/O Expansion: Extending field wiring capabilities from a Remote I/O Rack (P/N 16426-1) to junction boxes.
QUADLOG Systems: Providing secure signal paths for safety-critical I/O modules.
Pre-assembled Length: 10-foot (3m) cable reduces on-site fabrication time and splicing errors .
Secure Mounting: Features a captive mounting screw on the module connector to prevent vibration loosening.
High Voltage Rating: Rated for 600 VAC, suitable for industrial control panel environments .
Strain Relief Support: Compatible with the chassis tie-points to prevent connector fatigue.
Shielded Construction: Protects signal integrity against electromagnetic interference (EMI) in noisy plants.
Signal Routing: Transmits input/output signals between the I/O module and the field termination assembly.
Power Delivery: Carries 24V DC loop power from the backplane to field devices via the termination assembly.
Module Interface: Acts as the physical bridge allowing hot-swappable replacement of I/O bricks.
Physical Layer Connection: Replaces hardwiring between the backplane and terminal blocks, organizing the system backbone.
Q1: What systems is the SIEMENS 16137-114 compatible with?
A1: It is compatible with Siemens APACS+, QUADLOG, and APACS MBX I/O modules in Remote I/O Racks.
Q2: How long is the 16137-114 cable?
A2: The cable measures 10 feet (3 meters) from end to end .
Q3: Is the 16137-114 cable terminated on both ends?
A3: No. It has a molded connector for the module end and unterminated stripped wires for the marshalled termination assembly end.
Q4: Can I use this cable for the IOBUS network?
A4: No. The 16137-114 is strictly for I/O field wiring; use shielded twisted-pair cables for IOBUS connections.
Q5: What voltage is the SIEMENS 16137-114 rated for?
A5: It is rated for 600 VAC, making it suitable for industrial control circuits .
