SIEMENS · SIMATIC S7-200 SMART
6ES7288-1CR60-0AA0
CPU CR60 AC/DC/Relay Compact CPU
|
ONBOARD I/O
36 DI
24 DO Relay outputs
|
|
Supply: AC 85–264 V · Memory: 20 KB · Selection: RS485 serial CPU; no onboard Ethernet
Email InquiryWhatsApp[email protected] | +86 18159889985 |
|
ONBOARD I/O
60 digital points
36 DI · 24 relay DO
|
MEMORY
20 KB total
Program and data
|
CPU POSITIONING
Serial / fixed I/O
No onboard Ethernet
|
|
Local digital control
High onboard I/O count for compact machines and panels. |
Relay switching
Relay outputs for suitable discrete loads after load verification. |
Serial integration
RS485-based programming or device communication. |
|
Product type
|
CPU CR60 compact CPU, AC/DC/relay
|
|
Onboard inputs
|
36 digital inputs, 24 V DC
|
|
Onboard outputs
|
24 relay digital outputs, up to 2 A
|
|
Power supply
|
85–264 V AC, 47–63 Hz
|
|
Memory
|
20 KB program/data memory
|
|
Dimensions
|
175 × 100 × 81 mm
|
|
Available
Integrated RS485 serial/programming interface. Engineering uses STEP 7 Micro/WIN SMART. |
Not provided
No onboard Ethernet. CR CPUs do not support expansion modules or signal boards. |
|
Mounting
Standard DIN rail installation. |
Declarations
EMC, LVD and RoHS product families. |
Installation
Use a suitable industrial enclosure and protective devices. |
|
01
|
Isolate power and verify the 85–264 V AC supply range.
|
|
02
|
Check input commons, relay loads, protective devices and conductor ratings.
|
|
03
|
Provide required grounding and separation for power and signal wiring.
|
|
04
|
Confirm the RS485 cable, protocol, HMI and device addressing.
|
|
05
|
Match the CPU hardware and firmware with the intended project.
|
|
Complete article number: 6ES7288-1CR60-0AA0
|
CPU CR60, AC/DC/relay
|
|
36 DI and 24 relay DO
|
No onboard Ethernet; no expansion modules
|
|
Required firmware/project compatibility
|
Current product/nameplate photos: available on request
|
|
Stock status
|
Subject to verification before quotation
|
|
Condition
|
New / Used / Refurbished: confirm before quotation
|
|
Photos and test
|
Current unit/nameplate photos available on request; test scope subject to verification
|
|
Warranty and dispatch
|
Confirm before quotation
|
|
Payment terms
|
Available on request and confirmed on quotation
|
|
Quote response
|
Subject to verification after complete inquiry details are received
|
