SIEMENS SIMATIC ET 200SP 6ES7510-1DJ01-0AB0 CPU 1510SP-1 PN Central Processing Unit

SIEMENS SIMATIC ET 200SP 6ES7510-1DJ01-0AB0 CPU 1510SP-1 PN Central Processing Unit

SIEMENS · SIMATIC ET 200SP

6ES7510-1DJ01-0AB0

CPU 1510SP-1 PN Central Processing Unit

OFFICIAL LIFECYCLE

SPARE PART

Cancelled product

Program

100 KB

Data

750 KB

Network

IRT · 3 ports

Bit time

72 ns

Selection gate: Confirm MLFB, FS and firmware, TIA Portal project, memory card, BusAdapter, ET 200SP station and successor strategy.

Direct inquiry

Email Inquiry WhatsApp[email protected] | +86 18159889985

Overview
Applications
Data
Construction
Environment
Installation
Verification
Commercial
Models
Recommended Products

Official product overview

CPU 1510SP-1 PN Central Processing Unit

CPU 1510SP-1 PN for ET 200SP with 100 KB program work memory, 750 KB data work memory, PROFINET IRT three-port switch, 72 ns bit performance, required SIMATIC Memory Card and required BusAdapter for ports 1 and 2.

Exact MLFB

6ES7510-1DJ01-0AB0

Family

SIMATIC ET 200SP

Status

SPARE PART

Lifecycle: Siemens lists 6ES7510-1DJ01-0AB0 as cancelled since 01.10.2024 and identifies 6ES7510-1DK03-0AB0 as successor. Migration must be engineered.

Applications

Compact ET 200SP controller with integrated PROFINET

Execute the engineered control program in an ET 200SP station.
Connect PROFINET devices through the integrated IRT interface and three-port switch.
Use the CPU in compact distributed automation architectures with matching ET 200SP modules.
Use configuration control, I&M data and system diagnostics where supported by the project.

Application note: Verify firmware, TIA Portal version, BusAdapter, memory card and complete module configuration before replacement.

Data

Product-specific values from Siemens official product data and manuals.

Work memory

100 KB + 750 KB

Interface

PROFINET IRT

Supply

24 V DC

Power loss

5.6 W

Product type	CPU 1510SP-1 PN
Hardware function status	FS05
Firmware reference	V2.9 in the current Siemens data sheet; verify quoted unit
Program work memory	100 KB
Data work memory	750 KB
SIMATIC Memory Card	Required; one slot; up to 32 GB load memory
PROFINET interface	IRT with integrated three-port switch
BusAdapter	Required for ports 1 and 2
Bit performance	72 ns
Rated supply	24 V DC
Supply range	19.2 to 28.8 V DC
Rated current	0.6 A
Typical power loss	5.6 W
TIA Portal	V17 for FW V2.9; V13 SP1 Update 4 or higher for FW V1.8

Construction

ET 200SP station integration, memory-card load memory and a three-port PROFINET interface.

Mode selectorOne mode selector is specified.	Memory-card slotSIMATIC Memory Card is required.
PROFINET switchIntegrated IRT-capable three-port switch.	BusAdapter interfacesCompatible BusAdapter required for ports 1 and 2.
ET 200SP integrationUse with documented station components.	24 V DC supplyObserve polarity and terminal assignment.
Status and diagnosticsUse indicators and online diagnostics.	Nameplate checksVerify MLFB, FS and firmware.

Environment

Use the CPU within the cabinet and ambient limits defined for ET 200SP.

Protection	Apply ET 200SP system-manual requirements
Environment	Dry industrial control cabinet
Operating temperature	Confirm for mounting orientation and hardware state
Storage / transport	Subject to official documentation verification
Altitude / derating	Apply ET 200SP system limits
EMC and grounding	Follow the ET 200SP system manual
Approvals	Verify current certificates for destination

Protection note: Module-level protection does not replace a suitable cabinet, grounding, network protection or complete-machine safety design.

Installation

Coordinate the ET 200SP station, supply, BusAdapter, memory card and project.

Station layoutConfirm CPU and module sequence.	24 V DC supplyUse official terminal assignment.
SIMATIC Memory CardInsert verified compatible card.	BusAdapterInstall correct article for ports 1 and 2.
PROFINET wiringUse approved industrial Ethernet components.	Project downloadMatch MLFB, firmware and TIA Portal project.
Module compatibilityVerify every module, BaseUnit and server-module requirement.	Final checkVerify device name, IP and diagnostics before RUN.

Verification

Confirm the exact article, hardware state and complete system context before replacement or quotation.

Exact MLFB	6ES7510-1DJ01-0AB0
Hardware / firmware	Read FS and firmware
Engineering version	Confirm TIA Portal and project firmware
Memory Card	Confirm type, capacity and contents
BusAdapter	Confirm article and media
ET 200SP station	Check modules and BaseUnits
Network topology	Confirm device name, IP and devices
Successor review	Assess 6ES7510-1DK03-0AB0 separately

Quotation input: Send CPU nameplate, firmware, memory-card details, BusAdapter MLFB, TIA Portal version and station list.

Commercial

FAQ and procurement answers use written verification instead of unsupported promises.

Stock

Confirm before quotation

Condition

Stated in writing

Evidence

Available on request

Is this confirmed in stock?	Confirm before quotation for the exact article, quantity and destination.
New, used or refurbished?	The quoted condition is stated in writing. No condition is assumed.
Can current photos be supplied?	Current overall-unit and nameplate photos are available on request.
Has the unit been tested?	Available on request and subject to the agreed inspection or test scope.
Warranty period	Confirmed in the formal quotation.
Dispatch time	Confirmed after stock, destination and order approval are verified.
Payment methods	Available on request in the formal quotation.
Quotation response	Subject to request completeness and verification.
How is the transaction verified?	Company details, quotation, invoice and beneficiary information are available for review before payment.
Compatibility	The official successor is not treated as automatic plug-and-play. Confirm project, firmware, memory, BusAdapter and station.
Included accessories	Memory Card, BusAdapter and station components are subject to verification and not assumed included.
Official product status	Siemens lists 6ES7510-1DJ01-0AB0 as cancelled since 01.10.2024 and identifies 6ES7510-1DK03-0AB0 as successor. Migration must be engineered.
