SIEMENS SIMATIC S7-1200 6ES7214-1AG40-0XB0 CPU 1214C Compact CPU DC/DC/DC | Subject to Verification

SIEMENS SIMATIC S7-1200 6ES7214-1AG40-0XB0 CPU 1214C Compact CPU DC/DC/DC | Subject to Verification

SIEMENS · SIMATIC S7-1200 6ES7214-1AG40-0XB0 CPU 1214C Compact CPU DC/DC/DC	COMPACT CPU CPU 1214C DC/DC/DC · 150 KB
Order check: Match CPU 1214C, DC/DC/DC construction, onboard I/O, memory and project version. Email Inquiry WhatsApp [email protected]\| +86 18159889985

Overview
Applications
Technical Data
Construction
Environment
Installation
Verification
Recommended Models
FAQ & Quote
Recommended Products

OFFICIAL PRODUCT OVERVIEW

CPU 1214C compact controller

SIMATIC S7-1200 CPU 1214C compact CPU with DC supply, transistor outputs and integrated digital and analog I/O. Siemens product data lists 14 digital inputs, 10 digital outputs, 2 analog inputs and 150 KB program/data memory.

Onboard inputs	14 digital inputs, 24 V DC; 2 analog inputs, 0–10 V DC
Onboard outputs	10 digital outputs, 24 V DC
Supply range	20.4–28.8 V DC
Program/data memory	150 KB

Applications

SYSTEM ROLE

Functions & Applications

Provides a higher onboard I/O count within the compact S7-1200 CPU range for machine and panel automation. Confirm scan, communication, expansion and technology requirements from the actual project before selection.

Technical Data

OFFICIAL DATA

Technical Data

Designation	CPU 1214C
Construction	DC/DC/DC compact CPU
Digital inputs	14 × 24 V DC
Digital outputs	10 × 24 V DC
Analog inputs	2 × 0–10 V DC
Supply	20.4–28.8 V DC
Program/data memory	150 KB
Compatibility	Confirm firmware and STEP 7 project requirements

Construction

HARDWARE VIEW

Interfaces & Construction

Integrated DI, DO and AI channels reduce separate I/O needs for matching applications. Verify the current terminal diagram, communication ports, supported expansions and mounting clearances in Siemens documentation.

Environment

OPERATING CONTEXT

Protection & Environment

Apply the official S7-1200 environmental and EMC limits for the exact article. Verify cabinet temperature, ventilation, grounding, conductor separation and approvals for the destination.

Installation

BEFORE COMMISSIONING

Installation & Selection

De-energize the panel, verify the 24 V DC supply, connect field wiring from the current terminal plan, mount with specified clearance, configure the exact CPU in STEP 7 and test diagnostics before operation.

Verification

ORDER CONTROL

Verification Checklist

Article number 6ES7214-1AG40-0XB0
CPU 1214C and DC/DC/DC construction
14 DI, 10 DO and 2 AI integrated I/O
20.4–28.8 V DC supply
150 KB program/data memory
Firmware and STEP 7 project compatibility
Current overall and nameplate photos
