Home > Products > SIEMENS > SIMATIC S7 Series
CAPACITY
4 MB
|
TECHNOLOGY
3.3 V Flash
|
STATUS
PM300 Active
|
Program card |
Firmware update |
Project storage |
Spare replacement |
|
Article number
6ES7954-8LC04-0AA0 |
Memory
4 MB |
Flash
3.3 V |
|
Net weight
0.017 kg |
Packaging
9.20 x 11.50 x 0.32 cm |
Origin
Germany |
|
EAN
4047623411970 |
UPC
195125456860 |
Lifecycle
PM300: Active Product |
|
Official device family
|
S7-1x00 CPU and SINAMICS.
|
|
S7-1200
|
Listed by Siemens as an optional SIMATIC Memory Card accessory.
|
|
S7-1500
|
Functions are documented in the Siemens CPU-memory manual.
|
|
Predecessor
|
Functionally compatible with 6ES7954-8LC03-0AA0 for spare-part replacement.
|
|
Capacity selection
|
Confirm that 4 MB is sufficient for the project, firmware and user files.
|
|
Device verification
|
Confirm the CPU or drive MLFB, firmware and STEP 7 version before quotation.
|
|
RoHS
Compliance recorded by Siemens since 16 February 2023. |
WEEE
Take-back obligation is listed as applicable. |
|
Export control
AL: N / ECCN: N. |
REACH
Use the current Siemens product declaration. |
|
Operating limits
Subject to the applicable CPU or drive documentation. |
Handling
Protect the card and stored project data during transport and installation. |
|
01
|
Confirm the target CPU or SINAMICS device and the required 4 MB capacity.
|
|
02
|
Use a Siemens-supported card reader and STEP 7 procedure.
|
|
03
|
Set Program card or Firmware update card according to the intended function.
|
|
04
|
Switch off the CPU before card replacement when following the retentive-data procedure.
|
|
05
|
Do not delete the protected __LOG__ or crdinfo.bin files.
|
|
06
|
Back up required project and user files before formatting or reuse.
|
|
Physical stock
|
Confirm before quotation.
|
|
Condition
|
New, used or refurbished status is subject to verification.
|
|
Current photographs
|
Available on request, including package and label views.
|
|
Warranty
|
Available on request and stated in the quotation.
|
|
Dispatch time
|
Confirm before quotation.
|
|
Testing
|
Read/write or authenticity-verification status is subject to verification.
|
|
Payment methods
|
Available on request and stated in the proforma invoice.
|
|
Quotation response
|
Timing depends on availability and compatibility verification.
|
|
Transaction process
|
An itemized quotation, company details, invoice, pre-shipment verification and shipment records can be provided as applicable.
|
|
