Triconex Invensys DI3301 DI 3301 Digital Input Module

Triconex Invensys DI3301 DI 3301 Digital Input Module

Product Name: Digital Input Module

Brand Name: Triconex Invensys

Model Number: DI3301 DI 3301

Place of Origin: USA

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

triconex invensys di3301 di 3301 digital input module-1

Overview
Specifications
Commercial Terms
Description
Features
FAQ
Other Brand
Why Choose Us
Recommended Products

Contact Info

Sales	Email	Phone/Whatsapp
Jim Pei	[email protected]	+86 18020776782

Specifications

Product Name	Triconex Invensys DI3301 DI 3301 Digital Input Module
Manufacturer	Triconex Invensys
Product Type	Digital Input Module
Part Number	DI3301 DI 3301
Weight	1.32kg
Estimated shipping dimensions	4.3x18.8x21.8cm
Place of shipment	Xiamen, China
Country of origin	USA
Number of Input Points	32, Commoned
Nominal Input Voltage	24 VDC
Operational Voltage Range	15–30 VDC
Absolute Maximum Input Voltage	33 VDC
Absolute Maximum Reverse Input Voltage	-0.6 VDC
Input Delay	<10 ms, On-to-Off or Off-to-On
Input Delay Time Constant	TC = 6.4 ms, -3 dB @ 25 Hz
Input Impedance	>30 kΩ without baseplate; ≈3 kΩ with baseplate
Input Power @ 24 VDC	0.2 W/point
Input Power @ 33 VDC	0.5 W/point
OFF Region	0–5 VDC
Transition Region	6–14 VDC
ON Region	15–30 VDC
Diagnostic	Force-to-value diagnostic (FVD)
Diagnostic Test Time	<2 ms/test
Maximum Input Toggle Rate for Diagnostic Fault Coverage	<20/sec
FVD Off-State Glitch Duration	<2 ms
FVD Off-State Glitch Magnitude	≈36% test voltage
FVD Output Impedance	0–5 VDC, ≈100 kΩ
ADC Scan Time	<1 ms for all 32 points
Functional-to-Protective-Earth Isolation	500 VDC minimum
Functional-to-Functional-Earth (Logic) Isolation	800 VDC minimum
I/O Architecture	Triplicated I/O Bus
Front Panel Indicators	PASS, FAULT, ACTIVE, FIELD PWR + 32 Point Indicators

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Description

The Triconex Invensys DI3301 is a 32-point Digital Input Module designed for high-integrity industrial control and safety system applications. It provides 32 commoned 24 VDC input points with a 15–30 VDC operational range and fast signal acquisition for reliable monitoring of switches, sensors, contacts, and other discrete field devices. The module incorporates Force-to-Value Diagnostic (FVD) functionality, triplicated I/O bus architecture, and comprehensive channel status indication to support continuous diagnostics and dependable field signal processing. It is well suited for safety instrumented systems, emergency shutdown, process protection, fire and gas, and other critical industrial applications.

Features

Provides 32 digital input points in a single module for high-density monitoring of industrial field signals.
Designed for nominal 24 VDC inputs with a 15–30 VDC operational range for compatibility with common industrial discrete devices.
Triplicated I/O bus architecture supports high-integrity signal processing within compatible Triconex safety system configurations.
Force-to-Value Diagnostic (FVD) functionality provides active testing of input circuits to help identify potential faults.
Diagnostic tests are completed in less than 2 ms, supporting continuous fault detection with minimal impact on normal signal monitoring.
ADC scanning of all 32 input points is completed in less than 1 ms for rapid acquisition of field conditions.
Input response of less than 10 ms supports timely detection of changing process and safety signals.
Electrical isolation between functional circuits and protective or logic earth helps improve system protection and signal integrity.
PASS, FAULT, ACTIVE, and FIELD PWR indicators provide convenient module-level diagnostic information.
Individual indicators for all 32 input points simplify commissioning, troubleshooting, and maintenance of connected field circuits.

FAQ

Q1: What is the Triconex Invensys DI3301 DI 3301?
The DI3301 DI 3301 is a 32-point digital input module designed for monitoring discrete field signals in compatible Triconex industrial control and safety systems.

Q2: How many input points does the DI3301 provide?
It provides 32 commoned digital input points in a single module.

Q3: What input voltage does the DI3301 support?
The module uses a nominal 24 VDC input and has a specified operational voltage range of 15–30 VDC.

Q4: What is Force-to-Value Diagnostic on the DI3301?
The DI3301 uses Force-to-Value Diagnostic (FVD) testing to help detect faults in input circuits while supporting continuous system diagnostics.

Q5: How fast does the DI3301 respond to input changes?
Its specified input delay is less than 10 ms for both ON-to-OFF and OFF-to-ON transitions.

Q6: Does the DI3301 support triplicated I/O architecture?
Yes. The DI3301 uses a triplicated I/O bus architecture for integration into compatible high-integrity Triconex system configurations.
