Product Name:proximity measurement system
Brand Name:Vibro-Meter
Model Number:TQ403 111-403-000-012
Country of Origin:Switzerland
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
Vibro-Meter |
Model Number: |
TQ403 111-403-000-012 |
Country of Origin: |
Switzerland |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Item | Specification |
|---|---|
| Model | TQ403 111-403-000-012 |
| System Type | Eddy-current non-contact proximity system |
| Measurement Range | 12 mm |
| Frequency Response | DC to 20 kHz (−3 dB) |
| Output Type | Voltage or current |
| Operating Temperature | −40°C to +180°C |
| Cable Type | Coaxial integral + EA403 extension |
| Protection Rating | IP68 (sensor tip) |
| Hazardous Area | Ex ia / Ex nA versions available |
| Weight | Approx. 140 g |
The TQ403 111-403-000-012 is part of Meggitt’s vibro-meter® eddy-current proximity system designed for high-precision, non-contact shaft displacement and vibration measurement. When paired with the IQS450 signal conditioner, the system delivers stable and calibrated monitoring of rotating machinery in demanding industrial environments. It is widely used in turbines, compressors, pumps, and alternators where accurate dynamic position tracking is required.
The system provides a measurement range up to 12 mm with excellent linear response and a frequency bandwidth from DC to 20 kHz. The TQ403 transducer and EA403 extension cable are fully interchangeable components, ensuring flexible installation and simplified maintenance across monitoring setups.
Built for harsh conditions, the system supports operation in extreme temperatures and hazardous zones (Ex certified versions). It delivers either voltage or current output with strong noise immunity, making the TQ403 + IQS450 combination ideal for continuous machinery protection and condition monitoring applications.
Q1: What is the main use of TQ403 111-403-000-012?
A1: It is used for non-contact measurement of shaft vibration, displacement, and position in rotating machinery.
Q2: Is the TQ403 compatible with hazardous area installations?
A2: Yes, Ex ia and Ex nA certified versions are available for explosive environments.
Q3: What is the measurement range of this system?
A3: The system supports a linear measurement range up to 12 mm.
Q4: What output signals does the system provide?
A4: It supports both voltage and current output depending on configuration.
Q5: Which industries commonly use this proximity system?
A5: It is widely used in power plants, steel mills, chemical plants, and industrial automation systems.
|
