Product Name: Semi Iso RTD 200 Module
Brand Name: WOODWARD
Model Number: 5464-013
Country of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
WOODWARD |
Model Number: |
5464-013 |
Country of Origin: |
USA |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
Delivery time in stock |
Payment Terms: |
T/T |
Supply Ability: |
in stock |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
The 5464-013 is a semi-insulated input driver module from Woodward, purpose-built for the NetCon 5000 series distributed control platform. This 5464-013 module amplifies and converts weak sensor signals—including RTD temperature inputs, digital ON/OFF states, and analog 4–20 mA loops—into robust logic-level outputs for precise process control. The 5464-013 features 1500 VAC channel-to-channel isolation and sub-1 ms response time. With a wide –40°C to +70°C operating range and rugged industrial construction, the 5464-013 delivers reliable signal conditioning in turbine control, power generation, and heavy industrial automation environments
Semi-Insulated Isolation Architecture – 1500 VAC channel-to-channel isolation outperforms basic non-isolated drivers in electrically noisy environments, safeguarding against ground loops and voltage spikes
Multi-Signal Versatility – Handles RTD (Pt100/Pt1000), digital ON/OFF, 4–20 mA, 0–10 V, and ±10 V inputs, reducing the need for multiple specialized modules
High-Speed Signal Processing – ≤1 ms response time with 16-bit resolution and 10 ms per channel sampling rate ensures real-time acquisition for time-critical control loops
Seamless NetCon 5000 Integration – Factory-matched to Woodward’s NetCon 5000 backplane communication protocol for plug-and-play compatibility
Extreme Environment Tolerance – –40°C to +70°C operating range with 5–95% RH non-condensing humidity tolerance suits outdoor, offshore, and unheated cabinet installations
Independent Channel Redundancy – Each channel operates with completely independent components; a chip or component failure affects only one channel
Multi-Channel Semi-Insulated Inputs – Multiple input channels with 1500 VAC electrical isolation between channels
RTD Temperature Signal Conditioning – Compatible with Pt100/Pt1000 resistance temperature detectors for precision temperature measurement
Flexible Analog Input Support – Accepts 4–20 mA, 0–10 V, and ±10 V signal types
Digital Input Capability – Handles 0–24 V DC discrete ON/OFF signals
High-Precision Conversion – 16-bit resolution with ±0.1% full-scale accuracy
Fault Diagnostics – Red LED indicator for module malfunction or signal anomaly detection
Industrial-Grade Construction – Embedded industrial board design with electromagnetic shielding for EMI immunity
Comprehensive Protection – Overvoltage, overcurrent, and short circuit protection
Compact Panel-Mount Form Factor – Space-efficient design suitable for dense control panels
The 5464-013 functions as a signal conditioning and interface module within Woodward’s NetCon 5000 distributed control system, bridging field sensors and the central controller. Upon receiving input signals from RTD temperature probes, digital switches, or analog transmitters, the module amplifies and converts these low-level or raw signals into standardized logic-level outputs (0–10 V DC or 0–200 mA) that the host controller can process. The semi-insulated design provides 1500 VAC isolation between channels, preventing ground loops and protecting the control system from electrical noise and voltage transients commonly found in industrial environments. The module supports real-time signal acquisition with ≤1 ms response time, enabling rapid detection of process deviations. It also incorporates fault detection circuitry that triggers a red LED indicator when signal anomalies or module malfunctions occur, facilitating rapid on-site diagnostics. In gas turbine applications, the 5464-013 monitors and controls two independent solenoid current inputs for low or high current failed trips, directly interfacing with fuel inlet solenoid valves. Each channel operates with fully independent components, ensuring that a single component failure affects only one channel. The module also supports 24/7 continuous operation in demanding industrial environments, with overvoltage, overcurrent, and short circuit protection built in
Q1: What is the Woodward 5464-013 used for?
The 5464-013 is a semi-insulated input driver module used for signal conditioning in Woodward NetCon 5000 control systems. It amplifies and converts RTD temperature, digital, and analog signals into logic-level outputs for turbine control, power generation, and industrial automation applications.
Q2: What types of input signals does the 5464-013 accept?
The 5464-013 accepts multiple signal types including RTD (Pt100/Pt1000) for temperature measurement, digital ON/OFF (0–24 V DC), and analog signals such as 4–20 mA, 0–10 V, and ±10 V.
Q3: What is the operating temperature range of the 5464-013?
The 5464-013 operates reliably from –40°C to +70°C with storage capability down to –85°C, making it suitable for extreme industrial environments including outdoor installations and unheated control cabinets.
Q4: Does the 5464-013 provide channel-to-channel isolation?
Yes. The 5464-013 features a semi-insulated design with 1500 VAC electrical isolation between input channels, effectively eliminating ground loops and protecting against electromagnetic interference.
Q5: Is the 5464-013 still in production?
No. The 5464-013 has been discontinued by Woodward. However, new old stock (NOS) and refurbished units remain available through authorized distributors and industrial automation suppliers with warranty coverage.
