Product Name: Flex 8 Point Thermocouple RTD Module
Brand Name: Allen-Bradley
Model Number: 1794-IRT8
Place of Origin: USA
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The Allen-Bradley 1794-IRT8 is an 8-channel FLEX I/O analog input module designed for high-accuracy temperature and low-level signal measurement in distributed industrial automation systems. It supports thermocouple, RTD (2-, 3-, and 4-wire), and millivolt inputs within a single compact module, providing flexible sensor integration while reducing cabinet space and wiring complexity. As part of the FLEX I/O platform, it integrates seamlessly with programmable controllers through FLEX I/O adapters and terminal base units, making it suitable for process monitoring, manufacturing, and industrial control applications.
Acquires temperature and low-level analog signals from thermocouples, RTDs, and millivolt sources.
Supports up to 8 input channels divided into two groups of four.
Converts analog signals with 14-bit resolution for accurate measurement.
Integrates with FLEX I/O distributed architectures through FLEX I/O adapters.
Supports firmware-based configuration, eliminating the need for hardware switches or jumpers.
Provides continuous monitoring of process temperature and sensor status for industrial automation systems.
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
| Product Name | AB 1794-IRT8 Flex 8 Point Thermocouple RTD Module |
| Manufacturer | Allen-Bradley |
| Product Type | Flex 8 Point Thermocouple RTD Module |
| Part Number | 1794-IRT8 |
| Weight | 0.1kg |
| Estimated shipping dimensions | 9.3x5.3x4.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | USA |
| Number of inputs | 8 channels (2 groups of 4) |
| Nominal input voltage ranges | 40…+100 mV DC for thermocouples, 0…325 mV for RTDs |
| Resolution | 14 bits |
| Common mode rejection | -80 dB @ 5V peak-to-peak, 50…60 Hz |
| Common mode input range, min | +15V |
| Isolation voltage (continuous voltage withstand rating) | 50V (continuous) |
| Open input detection time | Immediate detection (max 2 scans) |
| Overvoltage capability | 15V DC continuous at 25 °C |
| Overall drift with temperature, max | 50 ppm/°C of span |
| Cold junction compensation range | -20…+100 °C |
| Cold junction compensator | 1794-CJC2 |
| Flexbus | 5V DC, 40 mA |
| Power dissipation, max | 3.0 W @ 31.2V DC |
| Thermal dissipation, max | 10.2 BTU/hr @ 31.2V DC |
| Keyswitch position | -20°C to +70°C (-4°F to +158°F). |
Multi-Sensor Compatibility
Supports thermocouple, RTD, and millivolt inputs in a single module, reducing the need for multiple dedicated input modules.
Distributed I/O Flexibility
The FLEX I/O architecture enables remote installation close to field devices, minimizing wiring costs and simplifying system expansion.
Advanced Diagnostics
Built-in wire-off detection, CJC monitoring, and fast fault reporting help improve system availability and reduce maintenance time.
Reliable Measurement Performance
Delivers 14-bit resolution, excellent noise immunity, and strong common-mode rejection for stable measurements in industrial environments.
Simplified Configuration
Firmware-based setup eliminates hardware switches and jumpers, making commissioning faster and reducing configuration errors.
Compact Modular Design
Occupies minimal cabinet space while allowing scalable distributed I/O expansion as system requirements grow.
Industrial-Grade Reliability
Continuous isolation, overvoltage protection, and accurate cold junction compensation ensure dependable long-term operation in demanding applications.
