ABB AO820 3BSE008546R1 ANALOG OUTPUT MODULE

ABB AO820 3BSE008546R1 ANALOG OUTPUT MODULE

Product Name: NALOG OUTPUT MODULE

Brand Name: ABB

Model Number: AO820 3BSE008546R1

Place of Origin: Sweden

Warranty: 12 Months

Whatsapp：+86 18020776782

Email：[email protected]

Appurtenance:

abb ao820 3bse008546r1 analog output module-1

Overview
Contact Info
Parameter Information
Description
Functions
Features
FAQ
Recommendations
Recommended Products

Commercial Terms

Minimum Order Quantity	1 Piece
Price	Contact for Jim
Packaging Details	Original new Factory Sealed
Delivery Time	3–7 Days
Payment Terms	T/T
Shipping Method	DHL / FedEx / UPS / TNT
Supply Ability	In stock

Contact Info

Sales	Email	Whatsapp
Jim Pei	[email protected]	+86 18020776782

Parameter Information

Product Name	ABB AO820 3BSE008546R1 ANALOG OUTPUT MODULE
Manufacturer	ABB
Product Type	ANALOG OUTPUT MODULE
Part Number	AO820 3BSE008546R1
Estimated shipping dimensions	4.3x10.5x11.8cm
Weight	0.25kg
Place of shipment	Xiamen, China
Country of origin	SWEDEN
Resolution	12 bits including sign
Under/over range	±15%
Output load	≤ 550 Ω ≥ 5 kΩ (voltage output)
Temperature drift	Max 90 ppm/°C
Rise Time	< 0.7 ms
Update cycle time	≤ 1.5 ms
Rated insulation voltage	50 V
Channel Configuration	4 channels
Voltage output	±10 V
Isolation	Individually isolated channels
Maximum load resistance	500 Ω

Description

The ABB AO820 (3BSE008546R1) is a 4-channel analog output module designed for industrial automation and process control systems. It provides precise analog signal generation in both current and voltage formats, supporting integration with a wide range of actuators, drives, and control devices. With individually isolated channels and fast response performance, the module ensures reliable and stable operation in demanding industrial environments.

Functions

Converts digital control signals into analog output signals
Provides 4 independent analog output channels
Supports multiple output modes:
- Current output: 0–20 mA, 4–20 mA, ±20 mA
- Voltage output: ±10 V
Enables precise control of field devices such as valves, drives, and transmitters
Ensures electrical isolation between channels for safe and stable operation
Delivers fast signal updates for real-time process control

Features

4-channel analog output module
12-bit resolution including sign for precise signal conversion
Supports multiple output types: current (0–20 mA, 4–20 mA, ±20 mA) and voltage (±10 V)
Individually isolated output channels for high safety and low interference
Fast response performance with rise time < 0.7 ms
High-speed update cycle ≤ 1.5 ms for real-time control
Industrial-grade accuracy with temperature drift up to 90 ppm/°C
Under/over range capability of ±15%
Rated insulation voltage of 50 V
Maximum load resistance of 500 Ω (current output)

FAQ

Q1: What type of signals does the module AO820 3BSE008546R1 support?
A1: The module AO820 3BSE008546R1 supports analog current outputs (0–20 mA, 4–20 mA, ±20 mA) and voltage output (±10 V), making it suitable for various industrial control applications.

Q2: How many output channels does AO820 3BSE008546R1 have?
A2: The module AO820 3BSE008546R1 provides 4 independent analog output channels.

Q3: Are the output channels isolated in AO820 3BSE008546R1?
A3: Yes, in AO820 3BSE008546R1, each channel is individually isolated to improve noise immunity and system safety.

Q4: What is the resolution of AO820 3BSE008546R1?
A4: The module AO820 3BSE008546R1 has a 12-bit resolution including sign, ensuring accurate analog signal output.

Q5: What is the update speed of AO820 3BSE008546R1?
A5: The module AO820 3BSE008546R1 has an update cycle time of ≤ 1.5 ms and a rise time of less than 0.7 ms.

Q6: What is the maximum load supported by AO820 3BSE008546R1?
A6: The module AO820 3BSE008546R1 supports a maximum load resistance of 500 Ω for current output.
