Product Name: LAN Communication Module
Brand Name: ABB
Model Number: CS513 3BSE000435R1
Place of Origin: SWEDEN
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The ABB CS513 3BSE000435R1 LAN Communication Module is an industrial Ethernet and fieldbus communication interface module designed for reliable data exchange in automation systems. It enables communication between control systems and field devices using IEEE 802.3 Ethernet and supports PROFIBUS DP-V1 protocol with DP Master functionality. Built in a 19-inch Eurocard rack-mount structure, the CS513 is suitable for high-performance industrial control systems requiring stable and deterministic communication.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB CS513 3BSE000435R1 LAN Communication Module |
| Manufacturer | ABB |
| Product Type | LAN Communication Module |
| Part Number | CS513 3BSE000435R1 |
| Weight | 0.16 kg |
| Estimated shipping dimensions | 2.2x17x10.2cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Current consump. (A) | 5V 0.25, 24V 0.25 |
| Tot. power dissipation (W) | 8 |
| Communication Standard | IEEE 802.3 Ethernet |
| Structure | 19-inch rack-mount module (Eurocard structure) |
| Communication Protocol | PROFIBUS DP-V1 |
| Operating Mode | DP Master |
Dual Communication Capability
The CS513 supports both Ethernet (IEEE 802.3) and PROFIBUS DP-V1, providing more flexible system integration than single-protocol communication modules.
DP Master Functionality
As a DP Master, the CS513 can directly control and coordinate PROFIBUS network devices, improving system efficiency and reducing the need for additional controllers.
Industrial Rack-Mount Design
The 19-inch Eurocard structure ensures stable installation and compatibility with standard industrial control racks.
Reliable Power Efficiency
With low power consumption (5V and 24V at 0.25A each), the CS513 maintains efficient operation while supporting continuous industrial workloads.
High System Compatibility
Designed for ABB automation systems, it integrates easily with PLCs, drives, and distributed control architectures.
The ABB CS513 3BSE000435R1 LAN Communication Module is designed for installation in industrial 19-inch rack systems and operates using 5V DC and 24V DC power supplies. It is intended for controlled industrial environments within electrical cabinets or automation racks. With a total power dissipation of 8W, the module requires adequate ventilation for heat management. It should be protected from excessive humidity, dust, vibration, and electromagnetic interference to ensure stable communication performance in industrial applications.
Q1: What devices can ABB CS513 3BSE000435R1 connect to?
The CS513 3BSE000435R1 can connect PLCs, drives, distributed I/O modules, and other PROFIBUS or Ethernet-based industrial devices.
Q2: What communication protocols does CS513 3BSE000435R1 support?
The CS513 3BSE000435R1 supports IEEE 802.3 Ethernet and PROFIBUS DP-V1 protocols.
Q3: What is the operating mode of CS513 3BSE000435R1?
The ABB CS513 3BSE000435R1 operates as a DP Master in PROFIBUS networks.
Q4: What is the installation structure of ABB CS513 3BSE000435R1?
The CS513 3BSE000435R1 uses a 19-inch Eurocard rack-mount structure for industrial control systems.
Q5: What is the power consumption of ABB CS513 3BSE000435R1?
The ABB CS513 3BSE000435R1 consumes approximately 0.25A at 5V and 0.25A at 24V, with a total power dissipation of 8W.
Q6: Why is CS513 3BSE000435R1 used in industrial systems?
The CS513 3BSE000435R1 is widely used because it enables reliable dual-protocol communication, DP Master control capability, and stable integration in industrial automation networks.
