Product Name: SG-Interface Module
Brand Name: ABB
Model Number: DSXW110 57120001-PG
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
The ABB DSXW110 57120001-PG SG-Interface Module is an industrial signal interface module designed for sensor signal acquisition and processing in automation systems. It supports one measurement channel and provides a ±10 V sensor supply with a 320 Hz square-wave excitation signal, making it suitable for strain gauge and other bridge-based sensor applications. With 12-bit + sign analog output resolution, configurable voltage or current outputs, and 24 V DC digital I/O, the module ensures accurate and reliable signal conversion for industrial measurement and control.
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
| Product Name | ABB DSXW110 57120001-PG SG-Interface Module |
| Manufacturer | ABB |
| Product Type | SG-Interface Module |
| Part Number | DSXW110 57120001-PG |
| Weight | 0.44 kg |
| Estimated shipping dimensions | 2x25x24.5cm |
| Place of shipment | Xiamen, China |
| Country of origin | SWEDEN |
| Measurement Channels | 1 |
| Sensor Supply | ±10 V |
| Supply Signal Frequency | 320 Hz square wave |
| Input Signal | Sensor signal |
| Measurement Signal | Measurement output signal |
| Digital I/O (DI/DO) | 24 V DC |
| Analog Output (AO) Resolution | 12 bits + sign |
| Analog Output Range | 0 to ±10 V or 0 to ±20 mA |
Integrated Sensor Excitation
The DSXW110 provides a built-in ±10 V sensor supply with a 320 Hz excitation signal, reducing the need for external signal conditioning equipment.
Flexible Analog Output Options
It supports both voltage (0 to ±10 V) and current (0 to ±20 mA) outputs, offering greater compatibility with different control systems.
High Signal Accuracy
The 12-bit + sign resolution provides stable and precise analog signal conversion for industrial measurement applications.
Reliable Industrial Performance
Designed for continuous operation, the module ensures dependable signal processing in demanding automation environments.
Seamless ABB System Integration
The module integrates easily with ABB control systems, simplifying installation and improving overall system reliability.
The ABB DSXW110 57120001-PG SG-Interface Module is designed for installation in industrial control cabinets and automation systems. It operates with 24 V DC digital I/O and provides stable sensor signal processing for industrial measurement applications. The module should be installed in a clean, dry, and well-ventilated enclosure, protected from excessive dust, moisture, vibration, and electromagnetic interference to ensure reliable long-term operation.
Q1: What is DSXW110 57120001-PG used for?
The DSXW110 57120001-PG is used to interface and process sensor signals for industrial measurement and automation systems.
Q2: How many measurement channels does DSXW110 57120001-PG support?
The DSXW110 57120001-PG provides one measurement channel.
Q3: What sensor supply does DSXW110 57120001-PG provide?
The DSXW110 57120001-PG provides a ±10 V sensor excitation supply with a 320 Hz square-wave signal.
Q4: What analog output options are available on DSXW110 57120001-PG?
The DSXW110 57120001-PG supports analog outputs of 0 to ±10 V and 0 to ±20 mA.
Q5: What is the analog output resolution of DSXW110 57120001-PG?
The DSXW110 57120001-PG provides 12-bit plus sign analog output resolution.
Q6: What digital I/O does DSXW110 57120001-PG support?
The DSXW110 57120001-PG supports 24 V DC digital input and output signals.
