Product Name:IGBT Module
Brand Name:ABB
Model Number:FS450R12KE3/AGDR-71C S
Country of Origin:Sweden
Warranty:12 Months
Whatsapp：+86 18159889985
Email：[email protected]
Brand Name: |
ABB |
Model Number: |
FS450R12KE3/AGDR-71C S |
Country of Origin: |
Sweden |
Packaging Details: |
Original new Factory Sealed |
Delivery Time: |
in stock |
Payment Terms: |
T/T |
|
Sales Manager: |
Stella |
|
Send an email: |
|
|
Contact in Whatsapp: |
| Parameter | Details |
|---|---|
| Product ID | 68569354 |
| Model | FS450R12KE3 / AGDR-71C S |
| Manufacturer | ABB |
| Product Type | IGBT Module + Drive Kit |
| Voltage Rating | 1200 V |
| Current Rating | 450 A |
| Technology | ECONO+ IGBT |
| Application System | ABB ACS800 / ACS550 / ACS850 / ACQ810 |
| Kit Type | Drive replacement kit |
| Compatible Part Numbers | 68437024 / 3AUA0000109332 / 68561981 |
| Installation Type | Power module replacement |
| Protection Design | Industrial insulated power module |
| Switching Function | High-speed power switching |
| Operating Environment | Industrial drive systems |
| Net Weight | 1.1 kg |
| Dimensions | N/A (module-based assembly) |
The ABB FS450R12KE3 / AGDR-71C S (68569354) IGBT Module and Drive Kit is a high-power industrial switching solution designed for ABB ACS series drives and legacy low-voltage AC drive systems. It integrates a 1200V / 450A ECONO+ IGBT module with a dedicated gate drive unit, ensuring efficient power conversion and stable motor control performance.
The FS450R12KE3 / AGDR-71C S kit is widely used in ACS800, ACS550, ACS850, and ACQ810 drive platforms, providing reliable switching performance in demanding industrial environments. It is supplied as a complete replacement kit, supporting system maintenance and drive refurbishment applications.
Engineered for high reliability, the ABB 68569354 IGBT KIT improves energy efficiency, reduces switching losses, and ensures stable operation under heavy electrical loads, making it suitable for industrial automation, process control, and high-power motor drive systems.
Power Plants: Used in generator auxiliary drive systems; supports motor control and relay protection; improves energy efficiency in power generation equipment.
Substations: Supports auxiliary drive control systems; ensures stable switching performance in electrical infrastructure; enhances automation reliability.
Chemical Plants: Used in pump and compressor drive systems; supports stable process automation; improves energy efficiency in continuous production.
Steel Mills: Operates in high-temperature and high-EMI environments; supports heavy-duty motor control; enhances system robustness and reliability.
Machinery Manufacturing Plants: Used in automated production lines and robotic systems; supports precision motor control; improves manufacturing efficiency.
Q1: What is the ABB FS450R12KE3 / AGDR-71C S used for?
A1: It is an IGBT module and drive kit used for high-power motor control in ABB AC drive systems.
Q2: Which ABB drives are compatible with this IGBT kit?
A2: It is compatible with ACS800, ACS550, ACS850, and ACQ810 drive systems.
Q3: What is the voltage and current rating?
A3: The module is rated for 1200V and 450A (ECONO+ technology).
Q4: Is this a complete replacement kit?
A4: Yes, it includes both the IGBT module and AGDR-71C S gate drive unit.
Q5: What is the main benefit of this IGBT module?
A5: It improves switching efficiency, reduces losses, and ensures stable industrial drive operation.
|
