Product Name: Digital Slave Module
Brand Name: ABB
Model Number: NDSM05
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
Minimum Order Quantity |
1 Piece |
Price |
Contact for Jim |
Packaging Details |
Original new Factory Sealed |
Delivery Time |
3–7 Days |
Payment Terms |
T/T |
Shipping Method |
DHL / FedEx / UPS / TNT |
Supply Ability |
In stock |
|
Sales |
|
|
|
Jim Pei |
| Product Name | ABB NDSM05 Digital Slave Module |
| Manufacturer | ABB |
| Product Type | Digital Slave Module |
| Part Number | NDSM05 |
| Estimated shipping dimensions | 28x23.2x2.5cm |
| Weight | 0.44 kg |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Input Channels | 64 (high-density) / 16 / 8 variants reported |
| Nominal Voltage | 24 V DC |
| Input Type | Dry contact or voltage-driven |
| Response Time | < 5 ms (typically), < 1 ms reported |
| Isolation | Optical / 1500V AC |
| Operating Temp | 0°C to +60°C (industrial variant) |
| Storage Temp | -20°C to +85°C |
| Relative Humidity | 5% to 95% non-condensing |
The NDSM05 is a high-density Digital Slave Module developed by ABB for the Bailey INFI 90 and Net 90 Distributed Control Systems (DCS). It is designed to acquire and process multiple 24V DC digital input signals from field devices such as limit switches, push buttons, relays, and proximity sensors.
The module supports up to 64 discrete input channels in a single slot, making it an efficient and compact solution for industrial automation systems requiring large-scale signal monitoring. With optical isolation technology and a fast response time of less than 5 milliseconds, the NDSM05 ensures reliable signal transmission, noise immunity, and real-time system performance in demanding industrial environments.
The NDSM05 is widely used in power generation, water treatment, petrochemical, and metal processing industries where legacy ABB Bailey INFI 90 systems remain operational.
The primary function of the NDSM05 is to collect digital status signals from field devices and transmit them to the ABB Bailey INFI 90 or Net 90 controller for monitoring and control purposes.
The module continuously scans input channels and converts field device status changes into data signals readable by the DCS controller. Its fast response capability enables accurate detection of critical events and supports time-sensitive industrial operations.
The optical isolation feature enhances system reliability by preventing electrical interference from affecting the control system backplane. This makes the module particularly suitable for industrial environments with high electrical noise levels.
Typical applications include:
1. What is the NDSM05 used for?
The NDSM05 is a digital slave module designed for ABB Bailey INFI 90 and Net 90 DCS systems. It is used to acquire 24V DC digital input signals from field devices such as switches, relays, and proximity sensors.
2. How many input channels does the NDSM05 support?
The NDSM05 supports up to 64 digital input channels, providing a high-density solution for industrial digital signal monitoring.
3. What type of input signals can the NDSM05 process?
The NDSM05 is designed to process 24V DC discrete digital input signals from various industrial field devices.
4. What is the response time of the NDSM05?
The NDSM05 features a fast response time of less than 5 milliseconds, ensuring real-time detection of field signal changes.
5. Does the NDSM05 provide electrical isolation?
Yes, the NDSM05 includes optical isolation technology to protect the system from electrical noise, voltage spikes, and ground loop interference.
6. Which control systems are compatible with the NDSM05?
The NDSM05 is fully compatible with ABB Bailey INFI 90 and Net 90 Distributed Control Systems.
