Product Name: DDCS/ISA Adapter Board
Brand Name: ABB
Model Number: NISA-03
Place of Origin: Sweden
Warranty: 12 Months
Whatsapp：+86 18020776782
Email：[email protected]
| NAMC Board Interface | ABB ACS 600 Interface |
| Multi-Drive Expansion Module | DriveWare Communication Card |
| NDBU Branching Support | ISA 16-bit Interface Module |
| DDCS Protocol Module | Industrial Drive Communication Board |
| Industrial Automation Communication Card | ABB Drive Control Interface |
| ABB DriveWare Interface | Fiber Optic Communication Module |
| PC-to-Drive Adapter Board | ACx 600 Drive Adapter |
|
Minimum Order Quantity |
1 Piece |
|
Price |
Contact for Jim |
|
Packaging Details |
Original new Factory Sealed |
|
Delivery Time |
3–7 Days |
|
Payment Terms |
T/T |
|
Shipping Method |
DHL / FedEx / UPS / TNT |
|
Supply Ability |
In stock |
|
Sales: |
Email: |
Whatsapp: |
|
Jim Pei |
The ABB NISA-03 DDCS/ISA Adapter Board is a communication interface module designed for ABB ACS 600 (ACx 600) drive systems. Installed in a 16-bit ISA slot, it enables PC-based control and configuration of industrial drives via DriveWare software. The module uses dual fiber optic DDCS channels to ensure stable, high-speed communication between a computer and ABB drive systems.
| Product Name | ABB NISA-03 DDCS/ISA Adapter Board |
| Manufacturer | ABB |
| Product Type | DDCS/ISA Adapter Board |
| Part Number | NISA-03 |
| Weight | 0.1 kg |
| Estimated shipping dimensions | 2.5x12.7x17.8cm |
| Place of shipment | Xiamen, China |
| Country of origin | Sweden |
| Compatible Drives | ABB ACS 600 product series (ACx 600) |
| PC Slot Interface | 16-bit ISA slot |
| Companion Software | DriveWare PC software |
| Hardware Connection | NAMC of the drive |
| Multi-machine Connection Expansion | Supports signal distribution via NDBU series branch units |
| Transmission Media | Fiber Optic Cable |
| Number of Channels | 2 DDCS protocol fiber optic channels |
| Channel 1 Rate | 5 megabaud |
| Channel 2 Rate | 10 megabaud |
Dual Fiber Optic Channels
Improves communication flexibility and reliability.
PC-Based Drive Control
Enables direct configuration via DriveWare software.
Multi-Drive Expansion Support
Works with NDBU branching units for scalable systems.
High-Speed Data Transmission
Supports up to 10 megabaud communication rate.
Stable Industrial Communication
Optical fiber ensures noise-immune data transfer.
Compact ISA Card Design
Easy installation in standard PC ISA slots.
ABB Drive Compatibility
Specifically designed for ACS 600 drive systems.
Reliable Industrial Performance
Suitable for demanding automation environments.
Q1: What are the transmission speeds of ABB NISA-03?
A: NISA-03 supports two channels: 5 megabaud and 10 megabaud fiber optic communication.
Q2: What communication method does ABB NISA-03 use?
A: NISA-03 uses dual DDCS fiber optic communication channels for stable and high-speed data transfer.
Q3: Which drives are compatible with ABB NISA-03?
A: NISA-03 is designed for ABB ACS 600 (ACx 600) drive systems.
Q4: Can ABB NISA-03 connect to multiple drives?
A: NISA-03 supports multi-drive expansion through NDBU branching units, allowing multiple drives to be controlled in a network.
Q5: What software is used with ABB NISA-03?
A: NISA-03 works with ABB DriveWare software, including DriveWindow, for drive configuration and monitoring.
Q6: How is ABB NISA-03 installed?
A: NISA-03 is installed in a standard 16-bit ISA slot on a PC and connected via fiber optic cables to the drive system.
